ABRITES - AVDI - MI007 - Mitsubishi PIN and Key Manager

Available to Order
SKU: ABRITES-AVDI-MI007
NSID: 8297
$299.00
$660.00
$299.00

The key programming function currently works by utilizing the CAN-BUS interface. Keys can be programmed when the pin code of the vehicle is known. The Mitsubishi diagnostics has a database of default pin codes. The pin code can be changed with the Mitsubishi diagnostics. If the pin code is changed - the next time a key is programmed the new pin code should be used.

Please allow 24 to 48 hours to process

Description
Description
x

Currently, ALL VEHICLES based on the CAN-BUS protocol (2005+) are supported for key learning, including the latest 2017 models. This includes both key programming with and without a working key (ALL KEYS LOST) as well as the following functionality and manipulations of the Immobilizer module of the vehicles:

- Key registration - for vehicles that use a regular key
- Key registration (simplified) - for vehicles with ALL KEYS LOST or when the PIN Code is unknown
- Remote control registration
- KOS key registration - registration of smart keys for vehicles with Keyless Operation (Immo) Systems
- Key registration by ID - registration of a key by its (chip) ID
- Change PIN - change the Immobilizer System PIN Code
- Keycode and VIN Number registration to ECU - matching of the Engine Control Unit and Immobilizer module keycodes as well as matching of the Immobilizer VIN to the ECU VIN
- Steering Lock Unit registration - allows the customer to adapt the steering lock unit with the immobilizer system of the vehicle
- Use .PWF file for key registration - The customer would need to download a security application file (.PWF) from the Mitsubishi site, generated by providing the VIN (.PWF files need to be purchased separately).
- Reset immobilizer to factory state - Allows the customer to perform a factory-state reset of the immobilizer module. NB! After the procedure is complete, the immobilizer will require adaptation to the ECU as well as key programming. (Available for some KOS systems - for example, Outlander 2014+, Attrage/Mirage 2014+)
- Remote Control Reception Check - check the remote control function by pressing the lock/unlock buttons

NEW 2017+ support list:

  • "OUTLANDER" -2006 - 2018
  • "OUTLANDER PHEV" -2013 - 2019
  • "ASX/OUTLANDER/RVR" -2011 - 2018
  • "MIRAGE" -2012 - 2018
  • "MIRAGE G4" -2017 - 2018
  • "ATTRAGE/MIRAGE" -2014 - 2019
  • "SPACE STAR" 2013 - 2019
  • "CHALLENGER/PAJERO/MONTERO SPORT" -2009 - 2016
  • "PAJERO/MONTERO SPORT" - 2016 - 2018
  • "RVR" -2011 - 2018
  • "EK" -2014 - 2018
  • "MINICAB-MiEV VN" -2012 - 2017
  • "MINICAB-MiEV TK" -2013 - 2016
  • "EK SPACE" -2014 - 2018
  • "XPANDER" -2018 - 2019
  • "ENDEVOR" -2006 - 2011
  • "GALANT" -2006 - 2012
  • "ECLIPSE" -2006 - 2012
  • "ECLIPSE SPY" -2007 - 2012
  • "TRITON/L200" -2006 - 2015
  • "TRITON/L200/STRADA" -2015 - 2018
  • "LANCER SP" -2009 - 2017
  • "LANCER" -2008 - 2017
  • "380" -2006"i" -2006 - 2013
  • "ZINGER/FUZION" -2006 - 2015
  • "i-MiEV" -2009 - 2017
  • "DELICA D:5" -2007 - 2017
  • "GALANT/EVO" -2008 - 2015
  • "FORTIS SPORT" -2009 - 2015

ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
