Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8" Backset - ANSI Size - Hook Bolt - Radial Faceplate - Dark Bronze - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door
Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8"  Backset - ANSI Size - Hook Bolt - Radial Faceplate -  Dark Bronze  - Metal Door

Adams Rite - MS Deadlock - MS1851S-35X - 1-1/8" Backset - ANSI Size - Hook Bolt - Radial Faceplate - Dark Bronze - Metal Door

$37.30 $72.00
Available: In Stock
Wishlist
  • Product SKU: ADR-MS1851S-350-313
  • LIST PRICE: $72.00

    ADR-MS1851S-350-313
    Item Number: 6972

    The MS1850S-X5X Series MS® Deadlock answers the security need of sliding narrow stile aluminum doors in commercial, industrial, and institutional buildings. The locking mechanism is identical to the MS1850S Series MS Deadlock, except that the massive laminated bolt is provided in a hook shape to resist the parting motion of sliding door and jamb. The over-center maximum security (MS) locking action assures that forced entry attempts to pry the door in any direction, up, down, or sideways will be defeated.

    More Details Below

    •
    $37.30

Features

Backset  1-1/8" [28.6 mm]
Case Measures 1” x 6” x 2-1/4” [25.4 mmx 152.4 mm x 57.2 mm]. Steel with corrosion-resistant plating.
Bolt
 Hookbolt measures 5/8" x 1-3/8" [15.9 mm x 34.9 mm] with 13/16 [20.6 mm] throw. Hook shaped bolt repelspry bar attempts to “spread” the door from its jamb or lift it off its track
Faceplate Radial - Measures 1-1/4” x 8” [31.8 mm x 203.2 mm]
Door Types Metal Doors Only
Standard Package Individually boxed with faceplate and mounting screws.


Installation Instructions Download Here

Lock accepts any standard 1" [25.4 mm] length, 1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam. Cylinder Sold Separately

For hollow metal or wood doors prepared for hardware according to the specifications of the American National Standards Institute (ANSI), the MS1850SN Series MS® Deadlock provides maximum security and ease of installation.

Operation
360° turn of key or thumbturn projects or retracts the counterbalanced bolt. Key can be removed only when bolt is in a positively locked or unlocked position. Lock accepts any standard 1" [25.4 mm] length, 1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder, available separately or thumbturn such as the 4066 Thumbturn, available separately. Lock accepts cylinder from either or both sides.

LIST PRICE: $72.00

ADR-MS1851S-350-313
Item Number: 6972

The MS1850S-X5X Series MS® Deadlock answers the security need of sliding narrow stile aluminum doors in commercial, industrial, and institutional buildings. The locking mechanism is identical to the MS1850S Series MS Deadlock, except that the massive laminated bolt is provided in a hook shape to resist the parting motion of sliding door and jamb. The over-center maximum security (MS) locking action assures that forced entry attempts to pry the door in any direction, up, down, or sideways will be defeated.

More Details Below

  •

Features

Backset  1-1/8" [28.6 mm]
Case Measures 1” x 6” x 2-1/4” [25.4 mmx 152.4 mm x 57.2 mm]. Steel with corrosion-resistant plating.
Bolt
 Hookbolt measures 5/8" x 1-3/8" [15.9 mm x 34.9 mm] with 13/16 [20.6 mm] throw. Hook shaped bolt repelspry bar attempts to “spread” the door from its jamb or lift it off its track
Faceplate Radial - Measures 1-1/4” x 8” [31.8 mm x 203.2 mm]
Door Types Metal Doors Only
Standard Package Individually boxed with faceplate and mounting screws.


Installation Instructions Download Here

Lock accepts any standard 1" [25.4 mm] length, 1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam. Cylinder Sold Separately

For hollow metal or wood doors prepared for hardware according to the specifications of the American National Standards Institute (ANSI), the MS1850SN Series MS® Deadlock provides maximum security and ease of installation.

Operation
360° turn of key or thumbturn projects or retracts the counterbalanced bolt. Key can be removed only when bolt is in a positively locked or unlocked position. Lock accepts any standard 1" [25.4 mm] length, 1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder, available separately or thumbturn such as the 4066 Thumbturn, available separately. Lock accepts cylinder from either or both sides.

Compatible With
