Adams Rite - MS+ Deadlock - MS1890 - 1-1/8" Backset - LH or RHR - ANSI Size - Hook Bolt & Latch - Flat Faceplate - Flat/Standard Jamb - Aluminum - Metal Door - UHS Hardware
Adams Rite - MS+ Deadlock - MS1890 - 1-1/8" Backset - LH or RHR - ANSI Size - Hook Bolt & Latch - Flat Faceplate - Flat/Standard Jamb - Aluminum - Metal Door - UHS Hardware

Adams Rite - MS1890 - MS+ Deadlock - 1-1/8" Backset - LH or RHR - ANSI Size - Hook Bolt & Latch - Flat Faceplate - Flat/Standard Jamb - Aluminum - Metal Door

In Stock
SKU: ADR-MS1890-3015-628
NSID: 801

Get it shipped ! Order within:

Get it shipped ! Order within:

Get an Extra Hour with

$145.78
$253.00
$145.78

LIST PRICE: $253.00

ADR-MS1890-3015-628

The MS+1890 Series MS Deadlock/Deadlatch provides a maximum security deadlock for after hour and traffic control with deadlatch convenience during business hours.

Use for Maximum security MS+ deadlock after hours, plus the convenience of traffic control management during the business day. Typical installation is a bank or store requiring three modes of door control:

  1. Both lock and latchbolts retracted for unrestricted entry and exit during business hours
  2. Handle-operated latch for exit-only traffic just after closing
  3. Maximum security MS hookbolt for overnight lockup. When using trim (available separately) to activate, handle or paddle operates latchbolt only.

More Details Below

Call 1-800-878-6604 for Bulk / Dealer Pricing!

Features

Backset 1-1/8"[28.6 mm]
Case Measures 1" x 7-3/8" x depth [25.4 mm x 187.3 mm x depth] Steel with corrosion-resistant plating.
Bolt
Deadlock bolt: 5/8" x 1-3/8" [15.9 mm x 34.9 mm] with 13/16" [20.6 mm] throw. Eight-ply laminated stainless steel. Centerply has alumina-ceramic core to defeat any hacksaw attack, including rod-type “super” hacksaws, while hook shape repels pry bar attempts to “spread” the door from its jamb or lift it off its track.
Latchbolt: Measures 5/8" x 5/8" [15.9 mm x 15.9 mm] with 7/16" [11.1 mm] throw. Zinc alloy with Delrin face for smooth, quiet action. Handing easily reversible. Bolt can be held fully retracted to allow door to be free swinging
Faceplate Flat -
Strike Armored strike with satin stainless steel trimplate with steel mounting plate and dustbox. Flat strike furnished.
Handing RH or LHR
Door Types Metal Doors Only
Standard Package Individually boxed with faceplate and mounting screws.

Cylinder Sold Separately

Related Products: When purchasing this product, please consider the following related products which are available separately:

Accessories Cylinders Trim

Trim strikes including 4505 armored strike

4089 Exit Indicator

Standard 1" length, 1-5/32” diameter mortise cylinder with MS® cam such as 4036 Mortise Cylinder, 4066 Thumbturn; MS4043 Cylinder Guard

4560, 4565 Deadlatch Handles, 4568, 4569 Eurostyle Deadlatch Handles, 4590, 4591 Deadlatch Paddles


Installation Instructions Download Here

Lock accepts any standard 1" [25.4 mm] length, 1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam. Cylinder Sold Separately

For hollow metal doors prepared for hardware according to the specifications of the American National Standards Institute (ANSI), the MS1890 Series MS® Deadlock provides maximum security and ease of installation.

Operation
360° turn of key or thumbturn projects or retracts the hookbolt. 120° further turn retracts latchbolt as well. Lock accepts any standard 1" [25.4 mm] length,1-5/32" [29.4 mm] diameter mortise cylinder with MS® cam such as the 4036 Mortise Cylinder or thumbturn such as the 4066 Thumbturn, available separately. Lock accepts cylinder from either or both sides. When using trim (available separately) to activate, handle retracts spring-loaded latchbolt only. For door thickness other than 1-3/4”, please contact factory.

Compatible With
