Bolide / Hybrid DVR / 4 Channel / Control Over Coax / 5MP / 4K / 8TB HDD Interface / SVR9504H

Available to Order
SKU: BOL-SVR9504H
NSID: 23442

Please Note: This product has a lead time

$215.89
$259.07
$215.89

  • 4-Channel Inputs
  • H.265/H.264 Video Compression
  • PTZ Control
  • IP Hybrid DVR, Supports AHD / TVI / CVI/ Analog Formats
  • Records Up to 5MP, 4K Output,
  • HDMI and VGA Outputs
  • 4-Channel Audio In/ 1-Channel Audio Out
  • 1 SATA Hard Drive Bay Up to 8TB
  • Hard Drive Not Included ... sold seperately HERE
  • Offers QuickConnect


Call 1-800-878-6604 for Bulk / Dealer Pricing!

    Specifications:

    Record Resolution: Analog: 5MP/4MP/3MP/1080P/720P/960H
    IP: 4MP/3MP/1080P/720P/960H
    Record Speed: Analog: 5MP: 12fps (each ch) 4MP: 12fps (each ch) 3MP: 12fps (each ch) 1080P: PAL: 25fps (each ch)/NTSC: 30fps (each ch) 720P: PAL: 25fps (each ch)/NTSC: 30fps (each ch) 960H: PAL: 25fps (each ch)/NTSC: 30fps (each ch)
    IP: PAL: 25fps (each ch)/NTSC: 30fps (each ch)
    Display Resolution: Analog: 5MP (20fps) 4MP/3MP (30fps) 1080P/720P/960H
    IP: 1080P/720P/960H
    Feature: Single/Quad/S.E.Q.
    Video Compression: H.265/H.264
    Video System: NTSC/PAL
    Operating System: Embedded Linux
    Analog Video Input/Output: 4CH inputs/VGA& HDMI output
    Video Input: IP: Up to 2CH.
    Composite: Up to 6CH (Analog video & IP video)
    Audio Input/Output: 4CH inputs / 1 CH output (RCA)
    Recording Bandwidth:
    IP: 8Mbps. 32Mbps MAX
    Recording Mode: Continuous/Manual/Motion detect
    Simultaneous Playback: 4 Channels at once
    USB: 2 x USB (for mouse and backup)
    PTZ Control: Yes (RS485) Control over Coax
    HDD Interface: 1 SATA Hard Drive Bay Up to 8TB
    Hard Drive Not Included ... sold seperately HERE
    Multiplex Operation:
    Live display, record, playback, backup, and network
    Network Protocol: LAN, DHCP, and DDNS
    Voltage: 12VDC / 2Amps
    Working Temp: -10°C ~ 55°C
    Humidity: 10% ~ 90% Humidity
    Dimension: 300 x 227 x 53mm (11.8 x 8.9 x 2.1in)
