$117.09 $200.00
Available: In Stock
Wishlist
  • Product SKU: CMD-CM-120WV2
  • CMD-CM-120WV2
    Item number: 6909

    CM-120 Series keypads are North American built and provide Tri-Brid stand alone, Wiegand and optional wireless operation! CM120i offers the best performance and value for indoor applications. CM-120wV2 is a vandal and weather resistant model with a metal back-lit keypad.

    CM-120 Series hardwired keypads have added wireless functions by plugging in a CM-TX99 wireless transmitter module.

    • CM-120i keypad for indoor use, features stainless steel faceplate and polycarbonate keys
    • CM-120wV2 features backlit, weatherproof & vandal resistant metal keypad
    • Flush mount single gang stainless steel faceplate
    • 3 LED's + Piezo Buzzer
    • Request-to-Exit Input
    • Door contact input for anti-tailgating & door open alarm
    • Global lock-out feature
    • Includes tamperproof screws & driver
    • Option for plug-in TX-99 wireless transmitter, 2 channel
    $117.09

Customer Reviews

No reviews yet
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

Specifications:

Voltage:  12/24V AC/DC
Mounting:  Single gang, flush
(2) #6 machine and tamper proof screws
Current Draw:  30 mA Standby, 90 mA Max
Input:  1 x Rex Input / 1 x Door Contact Input
Contact Type:  2 x Form 'C'
Contact Rating:  3 AMPS @ 24 VDC
Capacity:  999 User Codes
Length:  Variable, Up to 8 Digits (10 Million Possible Codes)
Response Time:  0.3 Seconds
Time Delay:  1 to 255 Seconds, or Latched
Temp Range:  -40°F to + 122°F (-40°C to +50°C)
Dimensions:  4-1/2" x 2-3/4" x 3/4"
(114mm x 70mm x 19mm)
RF Output:  Optional Plug-In Transmitter, 2 Channel


Spec Sheets
  • CM-120_Spec Sheet_R2 pdf 0.55 DOWNLOAD
  • CM-120TX_Spec Sheet_R3 pdf 0.48 DOWNLOAD
Sales Sheets
  • CM-120 Series_Sales Sheet pdf 2.29 DOWNLOAD
Reference Guides
  • CM-120_Product Comparison pdf 0.17 DOWNLOAD
Manuals
  • CM-120_Manual_R4 pdf 1.11 DOWNLOAD
  • CM-120 Series Keypads_Programming Guide_R3 pdf 0.61 DOWNLOAD
  • CM-120 Series Keypads_Programming Guide_French_R3 pdf 0.76 DOWNLOAD
  • CM-120TX_Manual_R1 pdf 0.96 DOWNLOAD
  • CM-120TX_Manual_French_R1 pdf 0.44 DOWNLOAD
