$62.06 $106.00
Available: In Stock
Wishlist
  • Product SKU: CMD-CM-RQE70A
  • CMD-CM-RQE70A
    Item number: 6902

    Camden's CM-RQE70 PIR 'REQUEST TO EXIT' Detectors provide the latest word in design, with a complete list of "high performance" features, including secondary activation device input, door monitoring, two relay outputs, and tamper alarm. Many new programming, installation, and set-up features that have never previously been available.

    Camden started by making the CM-RQE70 smaller, so it can easily fit on door frames, and then made installing the detector faster and easier. CM-RQE70 comes with 4 factory default operating modes that can be selected with simple push buttons on the circuit board.

    Have an unusual installation and need custom settings? No problem. You can use the on-board push buttons to customize the default operating modes or program your own custom operating mode. CM-RQE70 isn't just a new REX detector, it's a whole new approach to REX detector design!

    • Compact size, designed to mount on door frames
    • Easy to use on-board programming buttons. No dip switches
    • (4) Factory default operating modes, with the ability to customize mode attributes
    • Selectable fail safe/fail secure
    • (2) Form ‘C’ contacts
    • Momentary and latching relay modes
    • Secondary activation device input
    • Card/keypad input
    • Door position switch input
    • Request to Exit input
    • Built-in sounder (adjustable)
    • Tamper switch
    $62.06

Specification:

Voltage:  12/24 VDC Operation
Current Draw:  50 mA (Max)
Relays:  (2) Form ‘C’ (DPDT)
Contact Rating:  3 A @ 30 VDC
Programming:  On-board push buttons and status LED
Modes:  (4) Factory Default
(1) Fully Custom
Selectable Fail Safe/Fail Secure
Coverage:  Max. 10’W x 10’H
Horizontal and Vertical Adjustment (Mechanical)
Sensor Sensitivity/Range (Electronic)
Time Delay:  Adjustable, 5, 15, 30, 45 & 60 second
Sounder:  ON/OFF, with Adjustable Volume
Piezo Buzzer:  92 db. @ 10cm
Indicator:  Activation LED
Card or Keypad Input:  (1) N/O
Door Position Switch Input:  (1) N/O
Request to Exit Input:  (1) N/O
Tamper Switch Contact Rating:  50 mA 12 VDC
Temp Operating Range:  32°F-120°F (0-50°C)
Humidity Range:  0- 93% Non-Condensing
Dimensions:  1-3/4"H x 7"W X 1-3/4"D
(43mm x 176mm x 43mm)
Weight:  0.25 Lbs. (0.12 Kg.)
Color:  White

CMD-CM-RQE70A
Item number: 6902

Camden's CM-RQE70 PIR 'REQUEST TO EXIT' Detectors provide the latest word in design, with a complete list of "high performance" features, including secondary activation device input, door monitoring, two relay outputs, and tamper alarm. Many new programming, installation, and set-up features that have never previously been available.

Camden started by making the CM-RQE70 smaller, so it can easily fit on door frames, and then made installing the detector faster and easier. CM-RQE70 comes with 4 factory default operating modes that can be selected with simple push buttons on the circuit board.

Have an unusual installation and need custom settings? No problem. You can use the on-board push buttons to customize the default operating modes or program your own custom operating mode. CM-RQE70 isn't just a new REX detector, it's a whole new approach to REX detector design!

  • Compact size, designed to mount on door frames
  • Easy to use on-board programming buttons. No dip switches
  • (4) Factory default operating modes, with the ability to customize mode attributes
  • Selectable fail safe/fail secure
  • (2) Form ‘C’ contacts
  • Momentary and latching relay modes
  • Secondary activation device input
  • Card/keypad input
  • Door position switch input
  • Request to Exit input
  • Built-in sounder (adjustable)
  • Tamper switch

Specification:

Voltage:  12/24 VDC Operation
Current Draw:  50 mA (Max)
Relays:  (2) Form ‘C’ (DPDT)
Contact Rating:  3 A @ 30 VDC
Programming:  On-board push buttons and status LED
Modes:  (4) Factory Default
(1) Fully Custom
Selectable Fail Safe/Fail Secure
Coverage:  Max. 10’W x 10’H
Horizontal and Vertical Adjustment (Mechanical)
Sensor Sensitivity/Range (Electronic)
Time Delay:  Adjustable, 5, 15, 30, 45 & 60 second
Sounder:  ON/OFF, with Adjustable Volume
Piezo Buzzer:  92 db. @ 10cm
Indicator:  Activation LED
Card or Keypad Input:  (1) N/O
Door Position Switch Input:  (1) N/O
Request to Exit Input:  (1) N/O
Tamper Switch Contact Rating:  50 mA 12 VDC
Temp Operating Range:  32°F-120°F (0-50°C)
Humidity Range:  0- 93% Non-Condensing
Dimensions:  1-3/4"H x 7"W X 1-3/4"D
(43mm x 176mm x 43mm)
Weight:  0.25 Lbs. (0.12 Kg.)
Color:  White
