Details
| Lock Function | ANSI F75 Passage lock |
| Handing | Non-Handed |
| Door Thickness | 1-5/8” to 1-7/8” |
| Cylinder | No Cylinder |
| Backset |
2 3/4" (70 mm) standard, Optional 2 3/8" (60 mm) sold separately HERE |
| Latch |
11-096 Deadlatch 1/2" (13 mm) throw |
| Hsg diameter | 1" (25 mm) |
| Levers | Rigid Lever - Pressure cast zinc |
| Thru Bolts | Removable thru-bolts fit existing preps like Schlage, Best, Yale, Corbin Russwin, Sargent, Arrow, and more |
| Strike | 10-025 1 3⁄16", 1 3⁄8" (30 mm, 35 mm) 1 1 ⁄4"x 47 ⁄8" (32 mm x 124 mm) ANSI |
| Finish | 626 - 26D - Satin Chrome |
| Certifications |
Meets or exceeds A156.2 performance requirements for grade 1 cylindrical locks. |
| Manufacturer Warranty | Limited lifetime mechanical warranty |
| Keyed Alike | Up to 10 KA10 |
