*Discontinued* Dahua / PoE Ethernet Switch / Industrial / 8-Port / 48-57 VDC / 120W / Managed / PFS4210-8GT-DP
Out of Stock
SKU:
DH-PFS4210-8GT-DP
NSID:
28317
- $683.98
-
- $683.98
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
DH-PFS4210-8GT-DP
The DH-PFS4210-8GT-DP is an 8-port Gigabit PoE Industrial Switch supports the IEEE 802.3af/at standard. Two of the ports support Hi-PoE to provide 60 W via a single port. The switch DH-PFS4210-8GT-DP is a Layer 2 managed industrial PoE switch and supports Web, SNMP and also CLI network management. The switch also supports ring network redundancy using standard STP/RSTP/MSTP protocols and also supports rich features such as VLAN, Link Aggregation, Port Mirroring, Flow Control, IGMP Snooping, SNMP, ROMN, ACL, QoS, and Static IP Routing. The switch is IP40-rated and DIN-rail mountable.
Features
- Layer 2 Managed Industrial PoE Switch
- Supports IEEE802.3af, IEEE802.3at, and Hi-PoE (60 W) Standards
- Supports STP/RTSP/MSTP for Network Redundancy
- Rich L2 Features, Including: VLAN, Link Aggregation, IGMP Snooping
- Web, SNMP, and CLI Management
- Ability to Daisy Chain Positive Terminals
- IP40 Ingress Protection, Fully-sealed Metal Enclosure
- Dual Power Input for Power Redundancy
- Wide Temperature Range for Industrial Applications
- Become a registered dealer of Dahua
- Call 1-800-878-6604 for Dealer Prices!
- $683.98
-
- $683.98
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
Description
x| Ethernet Ports | |
| Console Port | One (1) 1000 Base-X Port One (1) 10/100/1000 Base-T Port |
| Uplink Ports | Two (2) 1000 Base-X Ports |
| Downstream Ports | Eight (8) 10/100/1000 Base-T Ports (PoE Power Supply) |
| PoE Features | IEEE802.3af, IEEE802.3at: Ports 3 to 10 Consumption: Up to 30 W per port Hi-PoE: Ports 1 and 2 Consumption: up to 60 W per port Total PoE Budget: ≤ 120 W |
| PoE PIN Assignment | 1, 2 (V+), 3, 6 (V-) 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-) |
| Switching Capacity | 28 Gbps |
| Packet Forwarding Rate | 14.88 Mpps |
| Packet Buffer Memory | 4 MB |
| Power Consumption |
Static: ≤ 6 W Full Load: ≤ 120 W |
| Power Requirements | 48 VDC to 57 VDC Power Adapter |
| RS232 Serial Console | One (1) Port |
| RS485 | Two (2) Ports (9600 Baud Rate, TCP/UDP) |
| I/O | One (1) Input One (1) Output |
| Dimensions | 6.89 in. x 5.28 in. x 2.09 in. |
| Certifications | IP40 |
| Warranty | New Limited Lifetime |
