E-Plex - E2031 - Electronic Pushbutton Cylindrical Lever Set - Long Lever Set - 2¾" Backset - Optional Finish - Grade 1

In Stock
SKU: KABA-E2031LL62641
NSID: 2814 70929

Get it shipped ! Order within:

Get it shipped ! Order within:

Get an Extra Hour with

$379.13
$421.22
$379.13
Finish: Satin Chrome

The E-Plex 2000 Series provides exterior access by combination, while allowing free egress. This electronic pushbutton lock eliminates problems and costs associated with issuing, controlling, and collecting keys and cards. No Key Override

Features:

  • Requires no wiring to or through the door—eliminates risk of damage from pinched wires that can result in costly callbacks
  • Multiple Users—100 Codes
  • Non-handed; pre-assembled for left-hand door installations—easily changed in the field
  • The most recent 1,000 events are recorded in memory, including the use of mechanical key override. Software is required to view Audit Events.
  • Lock is easily programmed via keypad without removing lock from the door or with optional Microsoft Excel-based software.
  • PIN access
  • Five different authority levels allow who has access to specific lock functions, including: Master, Manager Level, Access User, Service, and Maintenance Level
  • User Parameters: Code length—adjustable to accept 4 to 8 digits
  • Anti-tamper lockout—adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
  • Re-lock time—adjustable from 2 to 20 seconds


Call 1-800-878-6604 for Bulk / Dealer Pricing!

Specifications:


Construction:

Heavy-duty commercial Grade 1 lockset, solid cast exterior housing, solid cast levers.

Locking Device:

Cylindrical ½" (13 mm) throw latch, floating face plate 2¾" (70 mm) backset

Numeric Keypad:

Vandal resistant, solid metal pushbuttons

Handing:

Non-handed, pre-assembled for left-hand door installation—easily changed in the field

Finish:

Satin Chrome 26D (626) / Satin Brass US4 (606)

Backset:

2¾" (70 mm) backset

Latch:

½" (13 mm) throw latch, floating face plate

Minimum Stile Recommended:

5" (127 mm)

Strike:

Cylindrical locks packaged standard with both ANSI A115.3 "T" Strike and A115.2 ASA Strike

Door Preparation:

ASA 161 (easily installs on door preparation with three additional through bore holes; wood or metal doors)

Door Thickness:

1⅜" (35 mm) to 2½" (64 mm); pre-assembled to accommodate doors 1⅝" (41 mm) to 2" (50 mm)

Accessibility Standard:

Americans with Disabilities Act (ADA)

Certification:

ANSI/BHMA Grade 1 Certified

Fire Rating:

3-hour UL/ULC fire rating for "A" label doors

Warranty:

3 years manufacturer warranty
