E-Plex - E2031XS - Electronic Pushbutton Cylindrical Lever Lock - Schlage 'C' - 2¾" Backset - Satin Chrome - Grade 1 - UHS Hardware
E-Plex - E2031XS - Electronic Pushbutton Cylindrical Lever Lock - Schlage 'C' - 2¾" Backset - Satin Chrome - Grade 1 - UHS Hardware

E-Plex - E2031XS - Electronic Pushbutton Cylindrical Lever Set - Schlage 'C' - 2¾" Backset - Satin Chrome - Grade 1

In Stock
SKU: KABA-E2031XSLL62641
NSID: 2835

Get it shipped ! Order within:

Get it shipped ! Order within:

Get an Extra Hour with

$405.91
$399.00
$405.91

The E-Plex 2000 Series provides exterior access by combination, while allowing free egress. This electronic pushbutton lock eliminates problems and costs associated with issuing, controlling, and collecting keys and cards.

Features:

  • Requires no wiring to or through the door—eliminates risk of damage from pinched wires that can result in costly callbacks
  • Multiple Users—100 Codes
  • Non-handed; pre-assembled for left-hand door installations—easily changed in the field
  • The most recent 1,000 events are recorded in memory, including the use of mechanical key override. Software is required to view Audit Events.
  • Lock is easily programmed via keypad without removing lock from the door or with optional Microsoft Excel-based software.
  • PIN access
  • Five different authority levels allow who has access to specific lock functions, including: Master, Manager Level, Access User, Service, and Maintenance Level
  • User Parameters: Code length—adjustable to accept 4 to 8 digits
  • Anti-tamper lockout—adjustable from 3 to 9 invalid attempts with an adjustable period of 0 to 90 seconds
  • Re-lock time—adjustable from 2 to 20 seconds


Call 1-800-878-6604 for Bulk / Dealer Pricing!

Specifications:

Construction:

Heavy-duty commercial Grade 1 lockset, solid cast exterior housing, solid cast levers.

Locking Device:

Cylindrical ½" (13 mm) throw latch, floating face plate 2¾" (70 mm) backset

Numeric Keypad:

Vandal resistant, solid metal pushbuttons

Handing:

Non-handed, pre-assembled for left-hand door installation—easily changed in the field

Finish:

Satin Chrome 26D (626)

Key Override:

Key-In-Lever, Kaba Cylinder (Schlage "C" Keyway) included

Backset:

2¾" (70 mm) backset

Latch:

½" (13 mm) throw latch, floating face plate

Minimum Stile Recommended:

5" (127 mm)

Strike:

Cylindrical locks packaged standard with both ANSI A115.3 "T" Strike and A115.2 ASA Strike

Door Preparation:

ASA 161 (easily installs on door preparation with three additional through bore holes; wood or metal doors)

Door Thickness:

1⅜" (35 mm) to 2½" (64 mm); pre-assembled to accommodate doors 1⅝" (41 mm) to 2" (50 mm)

Accessibility Standard:

Americans with Disabilities Act (ADA)

Certification:

ANSI/BHMA Grade 1 Certified

Fire Rating:

3-hour UL/ULC fire rating for "A" label doors

Warranty:

3 years manufacturer warranty
