Details
| Lock Function | ANSI F109 Entry / Office lock |
| Handing | Non-Handed |
| Levers | Falcon Quantum Style |
| Door Thickness | 1 3⁄8" to 1 3⁄4" standard. |
| Cylinder | Conventional cylinder, drilled with 6-pin chambers, pinned in 5 comes standard |
| Keyway | “G” keyway standard |
| Backset | 2 3⁄4" backset |
| Rose Diameter | Standard rose diameter 3 3⁄8" |
| Latch | 1⁄2" bolt projection made of stainless steel and UL listed for 3-hour door assemblies. Latches have self adjusting fronts to accommodate beveled or flat doors |
| Strike | ANSI curved lip strike 4-7⁄8" x 1-1⁄4" x 1-1⁄4" lip to center standard. |
| Finish | 626 - 26D - Satin Chrome |
| Certifications |
All locks shall meet ANSI/BHMA A156.2, Series 4000, Grade 2 test requirements for key-in-lever locksets § Locksets shall be UL Listed 3-hour, A Label |
| Manufacturer Warranty | Limited lifetime mechanical warranty |
