Lockly - PGD678WSN - DUO Dual Locking Interconnected Smart Lock  - Fingerprint Reader - Phone App - WiFi - Touchscreen -  Key Override - Satin Nickel - UHS Hardware
Lockly - PGD678WSN - DUO Dual Locking Interconnected Smart Lock  - Fingerprint Reader - Phone App - Touchscreen -  Key Override - Satin Nickel - UHS Hardware
Lockly - PGD678WSN - DUO Dual Locking Interconnected Smart Lock  - Fingerprint Reader - Phone App - Touchscreen -  Key Override - Satin Nickel - UHS Hardware
Lockly - PGD678WSN - DUO Dual Locking Interconnected Smart Lock  - Fingerprint Reader - Phone App - WiFi - Touchscreen -  Key Override - Satin Nickel - UHS Hardware
Lockly Pro GUARD - PGD678W - DUO Dual Locking Interconnected Smart Lock  - Fingerprint Reader - Phone App - WiFi - Touchscreen - Key Override - Optional Finish - UHS Hardware

Lockly Pro - PGD678W - GUARD - DUO Dual Locking Interconnected Smart Lock - Fingerprint Reader - Phone App - Wi-Fi - Touchscreen - Key Override - Optional Finish

In Stock
SKU: LCK-PGD678WSN
NSID: 17501 24360

Get it shipped ! Order within:

Get it shipped ! Order within:

Get an Extra Hour with

$479.99
$539.99
$479.99

PGH230 Wifi Hub - Included

Built-In Optional Wired Sensor - IncludedLOCKLY PRO GUARD Duo is two locks in one featuring LOCKLY's Dual-Locking Technology to lock and unlock interconnected latch and deadbolt in a single lever motion for quick and easy access. Duo features LOCKLY's hack-proof PIN Genie keypad, fingerprint access, and smartphone control. Included Secure Link WiFi Hub adds voice assistant integration and 24/7 lock control/monitoring from anywhere in the world.

Duo details

Hack-Proof Digital Keypad Patented PIN Genie® touchscreen prevents codes from being guessed by randomly shuffling PIN number locations.

Your Finger is Your Key LOCKLY's 3D Biometric fingerprint sensor is unlike other optical readers that can often times be faked through images.

Send Offline Access Codes to people you trust Issue Offline Access Codes™ that do not require users to download an app or have WiFi or Internet connection to use.

Send eKeys to friends and family Grant one-time use or specific time duration access by issuing codes or digital eKeys remotely via a mobile device

Voice Control unlock, lock, or check door status by simply using your voice through Alexa or Google Assistant.

Full Control with Smartphone Unlock, lock, check door, track access history, and unique users in real-time from anywhere through free LOCKLY smartphone app.

One person, Advanced-DIY installation: Installs with basic household tools in about 30 minutes. Fits both left and right swinging standard doors, 1 3/8 to 2 inches thick.

Call 1-800-878-6604 for Bulk / Dealer Pricing!
Finish: Satin Nickel
Downloads

Specifications
Access Codes Stores up to 52 PIN access codes
RFID/Fob key Access Stores up to 999 MIFARE RFID/fob
Fingerprint Access Stores up to 99 biometric fingerprints
Remotely Shareable Temporary Access Unlimited* Offline Access Codes/ eBadges
Access Logs Unlimited Accessible via LocklyPro Commercial app or Lockly\OSTM
Visual and audible Exterior: LED (Red, Green) Interior: LED (Blue) Configurable Lock/Unlock Audio Indicator
Communication standards BLE 4.2 , Wi-Fi 2.4GHz , RF433.92MHz
Advanced Encryption Standard (AES), 256-bit
Command Response Responds to command from host in less than 3 seconds when linked to Lockly Wi-Fi Hub
0.2S on Fingerprint Recognition
Connectivity options LocklyPro Commercial app, Lockly\OS ALL in real-time communication
Battery Life AA Alkaline Batteries x 4 Up to 1 year (offline mode)
up to 10 months (regular use with App & Sensor
Operating temperature -4°F to 151°F (-20°C to 66°C)
Operating Humidity 0 - 100% non-condensing


Standards ISO 1444
Maximum read
range
RFID: up to 0.79"
BLE: up to 98’ (30m) Wi-Fi: up to 197' (60m)
RFID/Fob compatibility MIFARE® S50
Mobile compatibility LocklyPro Commercial app BLE 4.2
Lockly\OSTM

Mechanical Specifications
Handing Field reversible
Materials All-metal chassis and escutcheon
Door Thickness 1-3/8" - 2 1/4” (35mm- 50mm)
Backset Adjustable 2-3/8" or 2-3/4" (60mm or 70mm)
1" x 2 1⁄4" round corner faceplate
Strike Deadbolt: 1 1⁄8" x 2 3⁄4", round corner Latchbolt: 1 3⁄4" x 2 1⁄4", round corner,
Dust box included
Bore 2-1/8 " (54mm) diameter Bore hole
1" (25mm) diameter latch hole
Physical Keys SC1 Re-keying compatible, 2pcs included
RFID 3 x RFID Tag Keys Included

Measurements and Diagrams

Works with 4 and 5 1/2 inch deadbolt to latch bolt
spacing

Door thickness, backset, deadbolt and latch basic
installation measurements

DownloadsFor Easy Installation for any Lockly products - Download the BILT App - BILT has created a full how-to install graphical instructions for a streamlined, simple installation experience. Available on App Store and Google Play, which offers 3D video step-by-step instructions for assembly. Just search for the BILT app and then select the LOCKLY product you want to install.Installation Video:

Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Lockly directly at 669-500-8835 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.

Compatible With

Customer Reviews

Based on 7 reviews
71%
(5)
29%
(2)
0%
(0)
0%
(0)
0%
(0)
S
Steve V
Great lock

This is the only lock I could find that locked both the handle and the deadbolt at the same time. Not only that, but the lock is extremely well made and great looking. The installation took some time but worked out great once their customer support sent me a video which showed me what I had done wrong!

R
Robert Ellis
Lockly duo

Great lock with lots of features.

R
Robert Kearney
Best lock I can imagine

I love the lock. Installation was reasonably straightforward, with good instructions. Once it was installed, I had a chance to appreciate the complexity of the system, though using all those features was really quite simple. My only problem was one of misunderstanding what should have been obvious: I expected "Locked" meant both the deadbolt and latch bold had to be engaged. It was actually much simpler, and I was helped to that understanding by wonderful, patient customer relations.

Since I installed the lock, I have shown it to many friends, all of whom were quite impressed. I have also seen other locks in action, and was pleased at the comparison: I got the best.

T
Thomas Heidenreich

Lockly - PGD678WSN - DUO Dual Locking Interconnected Smart Lock - Fingerprint Reader - Phone App - Touchscreen - Key Override - Satin Nickel

L
Leon Weaver
Duo does all that was promised!

Hardware installation by general contractor and connectivity by homeowner was “glitch” free. User manual explanations were clear and easy to follow, although a bit more information about adding new users with Bluetooth would have been helpful. I had to turn WiFi “off” to do it. Mayb this should have been intuitive, but it took me a while to figure it out. Also user manual / software choices weren’t fully updated for Duo,
