Rosslare - AYCE65BG - Convertible Ultra Slim PIN - Proximity Reader - Controller - Grey
- Product SKU: ROS-AYC-E65BG
- NSID: 25278
-
ROS-AYC-E65BG
The ROS-AYC-E65BG is an unique ultra-slim profile, smooth metallic surface and high sensitive piezoelectric keys, now combined with shiny illuminated digits and a Proximity card reader makes this unit highly attractive for all-weather PIN & Prox access applications. The AYC-E65BG offers highly attractive yet durable solution for any need. Part of the Convertible line of readers/controllers, this unit can be operated as a keypad reader with any standard controller, and converts into a secure 500-users controller when connected to the PS-x5T intelligent power supply/relay unit.
Features:
- Ulta slim flush mount design
- Built-in piezoelectric keyoad for PIN code entry
- Programmable Patented blue backlit keypad
- Supports 4- to 8-Digit PIN credentials and 125 KHz EM type RFID cards and tags
- Smooth, attractive design, with all-weather indoor and outdoor operation
- Large, high-visibility unique illuminated piezoelectric keypad
- Optical back tamper detection output
| Operating Voltage Range |
5–16 VDC |
| Input Current | 92 mA @ 12 VDC |
| Input Current Max | 105 mA @ 16 VDC |
| Operating Temperature | -30˚C to 65˚C (-22˚F to 150˚F) |
| PIN Code Formats | 8 selectable formats, from 1 to 8 digit length PIN Codes |
| Dimensions | 155 x 44 x 9 mm (6.1 x 1.73 x 0.354 in.) |
Downloads:
