Simplex - 5010XS - Mechanical Pushbutton Combination Exit Trim Lever - Schlage 'C' - Satin Chrome - Grade 1
In Stock
SKU:
KABA-5010XSWL26D41
NSID:
2809
Get it shipped ! Order within:
Get it shipped ! Order within:
Get an Extra Hour with
- $444.13
-
$700.00 - $444.13
- Unit price
- per
Simplex Mechanical Pushbutton Locks eliminate problems and costs associated with issuing, controlling, and collecting keys and cards. The Simplex 5000 Series provides exterior access by combination, while allowing free egress.
Features:
- Fully mechanical lock eliminates the material and labor expense of battery replacements
- Single access code—one easy-to-manage code for all users
- Lock is easily programmed via keypad without removing the lock from the door
- Non-handed, pre-assembled for left-hand door installations—easily changed in the field
- Key-in-lever, Kaba Cylinder (Schlage “C” Keyway) included.
- Exit Trim—may be "dogged" if Exit Device allows
- Combination Entry
- Exterior Combination Change (only)
- Egress with Exit Device (not supplied)
- $444.13
-
$700.00 - $444.13
- Unit price
- per
Specifications:
Construction: |
Extra heavy-duty solid cast housings; solid cast levers, ADA-compliant levers, and wear tested for extensive use on indoor and outdoor applications |
Locking Device: |
Exit Trim, Not supplied (see list on below for compatibility) |
Numeric Keypad: |
Vandal resistant, metal pushbuttons |
Handing: |
Non-handed, pre-assembled for left-hand door installations—easily changed in the field |
Finish: |
Satin Chrome 26D (626) |
Key Override: |
K-I-L, Kaba Cylinder (Schlage “C” Keyway) included |
Backset: |
Varies by Exit Device |
Latch: |
Supplied with Exit Device |
Minimum Stile Recommended: |
5" (127 mm) |
Door Preparation: |
Easily installs on wood or metal doors. ASA 161 door preparation with additional through holes. |
Door Thickness: |
1¾" (44 mm) to 2¼" (57 mm). Pre-assembled to accommodate doors 1¾" (44 mm) to 2⅛" (54 mm). |
Accessibility Standard: |
Americans with Disabilities Act (ADA) |
Certification: |
ANSI/BHMA Grade 1 Certified |
Fire Rating: |
3-hour UL/ULC fire rating for "A" label doors |
Warranty: |
3 years manufacturer warranty |
Exit Device Compatibility—Simplex 5000 Exit Trim
- Arrow S1250, Dorex 8500R/8500F, Sargent 8888
- Arrow S3883F/S3800, Dorex 9500PR/9500FR, Von Duprin 22/22F
- Black & Decker (K-2) QED111/112, DORMA 9300/F9300, Von Duprin 98/98F
- Cal Royal 9800, Monarch 18R*, F18R*, Von Duprin 99/99F
- Cal Royal 2200, Precision 21/FL21, Von Duprin XP98/99
- Corbin Russwin ED5200/5200A, Sargent 2828, Yale YME2100/2100
- Detex 1001 BP1, Sargent 3828, Yale 7100
- Detex 10/F10 Series, Sargent 8810E/8800
*(requires special K-Hub Adapter)
Universal Lever Key-in-Cylinders: Includes dormakaba1599 6-pin cylinder (prepped to dormakaba 90 or Schlage "C" Keyway, keyed different) and tailpieces for compatibility with:
- Abloy 5277, Corbin Russwin 2000-03, Marks
- Abloy 5477, dormakaba 1539, Medeco 20W200H1
- Arrow C100, dormakaba Gemini 4730, Sargent 10 Line
- ASSA 65611, dormakaba Peaks 1099, Schlage 23-001
- ASSA 65691, dormakaba 1599, Schlage Primus 20-760
Australian: dormakaba expert 107K5, Boyd KC286
European: Quattro S/Expert, AP2 (5 and 6-pin)
