TownSteel - e-Elite 5010 - Electronic Push Button Lever Set - Bluetooth - Optional Backset - Rigid Lever Set - Satin Chrome - Key Override - Grade 1

In Stock
SKU: TNS-E-ELITE-5010BLE-26D
NSID: 7708

Get it shipped ! Order within:

Get it shipped ! Order within:

Get an Extra Hour with

The e-Elite 5000 is a modern, low profile lock with stainless steel latch bolt providing easy keyless access to your home using a highly responsive, 12-key illuminated touch and fingerprint resistant keypad programmable with up to 400 user codes interchangeable with RFID keycards/stickers. Mechanical key override lock is available as an extra back-up. The e-Elite 5010 comes with Bluetooth / BLE technology, lock programming with the TownSteel app TSE Home.

Apple iOS - Link HERE or Android - Link HERE

The e-Elite 5000 series is quick and easy to program

More Information Below

Call 1-800-878-6604 for Bulk / Dealer Pricing!
Backset: 2 3/4"

Features

  • 400 user codes interchangeable with RFID keycards/ stickers
  • Code Length: 6 to 10 digits, with anti-pry
  • Powered with 4 AA Alkaline batteries, up to 1 year battery life
  • System Settings: Passage Mode, Verification Mode, and Sound Adjustment
  • Bluetooth / BLE technology allows programming through our mobile app

TownSteel Gateway Required with Bluetootth / BLE and Wifi /RF - Lock Features

CLICK HERE

Specifications

Door Thickness: 1-3/4”
Backset 2-3/4” - 2-3/8"
Trim
Rigid Sentinel Lever
Latch bolt: Stainless steel, deadlocking, ½”throw
Faceplate 1-1/8“x 2-1/4”
Strike ASA strike standard, 1-1/4” x 4-7/8”
Key Override Yes
Cylinder 6 pin Schlage C keyway, standard
Power Supply
4AA batteries - No Hard wiring
Battery Life
Up to 1 year w/ Low Battery Alert
Certifications ANSI/BHMA - A156.2-2011 4000 Series Grade 1 Certified
UL - UL 10C 3-Hour Rated
ADA - Meet Requirements of The Americans with Disabilities Act
BAA - Meet Guidelines of The Buy American Act
Manufacturer Warranty 1-year limited for electronic
5-year limited for finish
10-year limited for mechanical

Downloads


Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Townsteel directly at 877-858-088, support@townsteel.com or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
