Uniview / UNV / 24 port POE Switch / UNV-POE-24T2GC

Out of Stock
SKU: UNV-POE-24T2GC
NSID: 7265
$529.00
$970.80
$529.00

NSW2010-24T2GC-POE-IN is Gigabit Uplink Unmanaged Switch which provides you with a high-performance, low-cost, easy-to-use, seamless and standard upgrade to boost your old network to 1000Mbps. Increase the speed of your network server and backbone connections, making Gigabit connection to a server or uplinking a network necessarily.
Its PoE ports can automatically detect and supply power with those IEEE 802.3af/at compliant Powered Devices (PD).
The electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as AP, IP Cameras or IP Phones, etc.

Call 1-800-878-6604 for Dealer Prices!

Key Features

  • Multiple working modes to address your business needs: Normal, Secure and Surveillance
  • Support port traffic control
  • Support for secure mode, all downlink ports can communicate only with uplink ports
  • Up to 250m transmission distance on surveillance mode
  • Support buffer optimization
  • All metal housing, safe and reliable

Call 1-800-878-6604 for Bulk / Dealer Pricing!


    Specifications

    Model

    Description

    Ports

    24×100Mbps PoE ports (RJ45)+2×1000Mbps Combo ports

    Standards

    IEEE802.3,IEEE802.3u,IEEE802.3z,IEEE802.3ab,IEEE802.3x,IEEE802.3af,IEEE802.3at,IEEE802.3az

    Switching capacity

    8.8Gbps

    Forwarding performance

    6.55Mpps

    Packet Buffer

    4Mbit

    MAC

    16K

    Dimensions (W×D×H)

    440mm x 207mm x 45mm(17.3"×8.1"×1.8")

    Weight

    <4.2kg

    Power supply

    AC: 100-240V, 50/60Hz

    PoE

    802.3at/af

    Max. PoE Power

    Max capacity: 370W

    Max capacity for single port: 30W

    Switch Power 390W
    Surge Protection Common mode ±6KV Differential mode ±4KV
    Electrostatic standard Common mode ±6KV Differential mode ±8KV

    Cooling Fans

    2

    Mean Time Between Failure(MTBF)

    >50000 hours

    Operating temperature

    0°C-40°C (32°F-104°F)

    Operating humidity

    10%~90% (noncondensing)

    Storage humidity

    5%~90% (noncondensing)

    Indicator

    PWR:
    Steady on: AC input is normal
    Off: No AC input

    Indicator PoE:
    Off: No PoE power supply
    Steady on: PoE power supply is normal
    Flashing: PoE power supply is abnormal

    Indicator

    LINK/ACT:
    Off: No link
    Steady: Linked at 10/100Mbps
    Flashing: Transmitting data

    Indicator Speed:
    Off: Linked at 10/100Mbps
    On: Linked at 1000Mbps

    Working Mode

    Default(Normal mode) : All ports can communicate with each other.

    VLAN(Secure mode): Downlink ports can communicate only with uplink ports.

    EXTEND(Surveillance mode): Transmission distance up to 250 meters.EXTEND(Surveillance mode): Transmission distance up to 250 meters.
