Uniview / UNV / IP / 8MP / Bullet Camera / Fixed / 2.8mm Lens / Outdoor / WDR / IP67 / 30m Smart IR / Active Deterrence / LightHunter / 3 Year Warranty / UNV-2128SB-ADF28KMC-I0
In Stock
SKU:
UNV-2128SB-ADF28KMC-I0
NSID:
7728
Get it shipped ! Order within:
Get it shipped ! Order within:
Get an Extra Hour with
- $349.00
-
$646.80 - $349.00
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
- 8MP; 2.8mm Fixed Lens
- Supports 256 GB Micro SD card.
- IP67 protection.
- True WDR 120dB
- Built-in Mic & Speaker.
- Smart IR up to 30m (98ft)
- Ultra 265, H.265, H.264, MJPEG
- Customer Service: USA: 800-860-7999 | Canada: 800-914-6008
- Call 1-800-878-6604 for Dealer Prices!
| Camera | |
| Sensor | 1/2.7", 8.0 megapixel, progressive scan, CMOS |
| Lens | 2.8mm@F2.0 |
| DORI Distance | Lens: 2.8mm Detect: 84m (275.6ft) Observe: 33.6m (110.2ft) Recognize: 16.8m (55.2ft) Identify: 8.4m (27.5ft) |
| Angle of View (H) | 112.4°~ 86.5° |
| Angle of View (V) | 60.1°~ 44.1° |
| Angle of View (O) | 146.1°~112.5° |
| Adjustment angle | Pan: 0° ~ 360° / Tilt: 0° ~ 80° / Rotate: 0° ~ 360° |
| Shutter | Auto/Manual, 1 ~ 1/100000s |
| Minimum Illumination | Color: 0.01Lux (F2.0, AGC ON) 0Lux with IR on |
| WDR | 120dB |
| Digital noise reduction | 2D/3D DNR |
| Day/Night | IR-cut filter with auto switch (ICR) |
| S/N | >56 dB |
| IR Range | Up to 30m (98ft) IR range |
| Wavelength | 850nm |
| IR On/Off Control | Auto/Manual |
| Defog | Digital Defog |
| Video | |
| Video Compression | Ultra 265, H.265, H.264, MJPEG |
| H.264 code profile | Baseline profile, Main Profile, High Profile |
| Frame Rate | Main Stream: 8MP (3840*2160), Max 25fps; 5MP (2944*1656), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), Max 30fps; CIF(352*288), Max 30fps; |
| Video Bit Rate | 128 Kbps~16 Mbps |
| ROI | Up to 8 areas |
| Privacy Mask | Up to 4 areas |
| OSD | Up to 8 OSDs |
| Motion Detection | Up to 4 areas |
| Image | |
| White Balance | Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
| Digital noise reduction | 2D/3D DNR |
| Smart IR | Support |
| Flip | Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
| Dewarping | Supported |
| HLC | Supported |
| BLC | Supported |
| Audio | |
| Audio Compression | G.711 |
| Suppression | Supported |
| Two-way audio | Supported |
| Sampling Rate | 8 KHZ |
| Storage | |
| Edge Storage | Micro SD, up to 256 GB |
| Network Storage | ANR |
| Intelligent | |
| Smart Intrusion Prevention | Cross Line, Intrusion, Enter Area, Leave Area detection; |
| Smart | |
| Basic Detection | Motion detection, Tampering alarm, Audio Detection |
| General Function | Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication |
| Network | |
| Protocols | IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, SNMP, HTTPS, SMTP, SSL |
| Compatible Integration | ONVIF (Profile S, Profile G, Profile T), API |
| Client | EZStation EZView EZLive |
| Web Browser | Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
| Interface | |
| Built-in Mic | Supported |
| Built-in Speaker | Supported |
| Alarm Light | Supported |
| Network | 1 RJ45 10M/100M Base-TX Ethernet |
| Certifications | |
| Certifications | CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
| General | |
| Power | DC 12V±25%, PoE (IEEE 802.3af) Power consumption: Max 10.5W |
| Dimensions (L×W×H) | 191× 75 × 74mm (7.5” × 3.0” × 2.9”) |
| Weight | 0.41kg (0.99lb) |
| Material | Metal |
| Working Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Strorage Environment | -30°C ~ 60°C (-22°F ~ 140°F), Humidity: ≤95% RH (non-condensing) |
| Surge Protection | 2KV |
| Ingress Protection | IP67 |
| Reset Button | Supported |
Downloads
Lighthunter Technology
The main goal of video surveillance is to see clearly anytime, anywhere. Cameras need to be well prepared for providing high-resolution and colorful images in different light conditions. The LightHunter Technology is an innovative technology that delivers vivid color, appropriate brightness, and extremely clear images in ultra-low light.
ONVIF COMPATIBILITY
If you want to add this camera to a security system already set up, that’s no problem. This camera complies with the protocols set by the Open Network Video Interface Forum (ONVIF). This means, as long as your current recorder is ONVIF compatible, you’ll be able to set this camera up with your current system.
If you want to add this camera to a security system already set up, that’s no problem. This camera complies with the protocols set by the Open Network Video Interface Forum (ONVIF). This means, as long as your current recorder is ONVIF compatible, you’ll be able to set this camera up with your current system.
