ABRITES - AVDI - VN015 - VAG - Odometer recalibration for VAG vehicles
Available to Order
SKU:
ABRITES-AVDI-VN015
NSID:
8270
- $1,199.00
-
$1,438.80 - $1,199.00
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
With the help of the VN015, you will be able to perform calibrations of the mileage in Volkswagen/Audi/Seat/Skoda/Bentley/Lamborghini and even some Porsche vehicles. It is very helpful when you need to replace a module that contains mileage information about the vehicle you are working on. Here is what you can do using this special function listed below:
Description
xMileage recalibration:
Cluster CAN:
Cluster K-Line:
Read/Update ConfData:
N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
- For Audi A6/A7 (4G) and A8 (D4) and VW Touareg 7P produced from 2010 until 2017 BY OBDII.
- The function works with UDS dashboards.
- Reading and updating internal control module configuration memory by diagnostics.
- Extracting and recalibration security access codes, PIN, component security bytes, current unit mileage values by K-line, CAN bus, and UDS.
Cluster CAN:
- With this function, you can establish a diagnostic session with the instrument cluster using KWP2000 over TP2.0 or UDS.
- You can Read/Update the odometer values. Supported types are: - VDO/MM/Visteon -2007 (CAN TP2.0)- VDO with NEC μC 2009+ (CAN UDS)- JCI with NEC μC
- and 95320 EEPROM (CAN UDS)- Magneti Marelli with 9S12 μC (CAN UDS)- A8(4H)/A7(4G)/A6(4G)/Touareg(7P) with 95320 EEPROM (CAN UDS)
Cluster K-Line:
- With this function, you can establish a diagnostic session with the Instrument cluster via K-Line
- (KWP1281 or KWP2000); You can Read/update the odometer value; Read PIN code; Read/Update ConfData; Read ROM/Flash from the Instrument cluster;
- Automatic removing of "DEF error" for Audi A4 instrument cluster BOSCH RB8. Supported types are:- VDO66/86, Motometer- External Immobilizer - LT,
- VW GOL, VW O GOL( Kostal ), Siemens 6 PIN HC05 Immo/TMS- Audi A4 B5 with/without board computer -1997- Audi A6 -1997- Audi A8 -1999- Magneti Marelli - Shadow 1/2/3/Direct-
- VW Sharan/Galaxy -2000- Audi A4 Bosch RBx/RB4/RB4 Crypto/RB8 Crypto 2004+- Golf 4 Bosch RBx- VW Phaeton/Touareg, Bentley Continental,
- Porsche Cayenne- Seat Exeo Bosch RB8 Crypto 2008+- Lamborghini Gallardo -2005/2005+
Read/Update ConfData:
- (VAG-EDC15x, VAG-ME7.1.1, VAG-ME7.1, VAG-ME7.5, VAG-Cartronic ME7.8.)
- Extracting Security access code / PIN (EDC15, ME7.x, VAG-Cartronic ME7.8) - Extracting Component security bytes
- (EDC15, ME7.x, VAG-Cartronic ME7.8)- Mileage Calibration (EDC15, EDC16)
N.B. Please note that you will require an AVDI interface with an active AMS in order to use this special function.
ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
Note: You will require an AVDI interface with an active AMS in order to use this special function.ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
Compatibility
xCompatible With
Notes
xNote: You will require an AVDI interface with an active AMS in order to use this special function.ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
Review
xNote: You will require an AVDI interface with an active AMS in order to use this special function.ALL SALES OF ABRITES PRODUCTS HARDWARE AND SOFTWARE ARE FINAL!
