Details
Software:
- Open source Android Operating System for fast boot-up and multitasking
- Easy and intuitive navigation makes finding what you need simple and fast
- Extensive vehicle coverage for more than 80 US, Asian and European commercial vehicle makes and machines
- Complete capabilities for codes, live data, actuation tests, adaptations
- Displays live data in text, graph, analog and digital gauge for easy data review and analysis
- Configures display options, sets triggers, records and playbacks results with one touch
- Records and playbacks live data to pinpoint troubles of sensors and components
- Cloud-based Data Manager saves customer and vehicle records, scanner data and technician notes
- Remote technical support for convenient demonstration, training and increased customer satisfaction
- Prints out recorded data anytime and anywhere with Wi-Fi technology
- Automatic Wi-Fi updates available in new software releases
Specifications:
| Operating System | Android™ 4.0, Ice Cream Sandwich |
| Processor | Samsung Exynos Quad-Core Processor 1.4GHz |
| Memory | 2GB RAM & 32GB On-board Memory |
| Display | 9.7 inch LED capacitive touchscreen with 1024x768 resolution |
| Connectivity |
Ethernet: RJ45 Ethernet Connection Wi-Fi (802.11 a/b/g/n) USB: 2.0 BT v.2.1 + EDR SD Card (Support up to 32GB) HDMI |
| Camera (rear) | Rear-facing, 5.0 Megapixel, AF with Flashlight |
| Sensors |
Gravity Accelerometer, Ambient Light Sensor (ALS) |
| Audio Input/Output |
Microphone Dual Speakers 4-Band 3.5 mm stereo/standard headset jack |
| Power and Battery |
11000 mAh 3.7 V lithium-polymer battery Charging via 12 V AC/DC power supply |
| Input Voltage |
12 V (9-24 V) |
| Power Consumption | 6.5 W |
| Operating Temp |
-10 to 55°C (14 to 131°F) |
| Storage Temp |
-20 to 70°C (-4 to 158°F) |
| Housing | Strong plastic housing with protective rubber boot |
| Dimensions | 300 mm (11.81”) x 220 mm (8.66”) x 50 mm (1.97”) |
| Protocols | SAE J1939; SAE J1708; Manufacturer customized J1939; Manufacturer customized J1708; KWP; VPW; UDS-CAN; CDL |
Accessories:
Autel USA Tech Support: 855-288-3587
Downloads:
Notes
Note: Remote technical support for convenient demonstration, training and increased customer satisfaction, Prints out recorded data anytime and anywhere with Wi-Fi technology, Automatic Wi-Fi updates available in new software releases.
Key programming machines cannot be returned after they have been registered
Autel Key Cutting and Programming Machines are made ONLY for use in North America (U.S.A., Canada). Not Caribbean Islands and Caribbean Regions, (Mexico, Guatemala, Belize, El Salvador, Honduras, Nicaragua, Costa Rica, Panama ). They are not intended to be used outside the U.S.A., and Canada, and some models may have region locks on certain software functions and hardware may not be compatible with regional infrastructure. If you intend to purchase this for use outside of the specified regions you do so at your own risk. The manufacturer will refuse the warranty claims and may refuse software support if it is determined being used outside of the designated region. UHS Hardware has the right to refuse sale of this product outside its designated region
