Details
Specifications
Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact Baldwin directly at 800-566-1986 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
| Configuration |
Deadbolt |
| Cylinder | Single Cylinder |
| Keyway | Baldwin 5 Pin C Keyway |
| Codes: | 4 to 8 Digit Codes |
| Handing | Reversible Left or Right |
| Finish | 112 - Venetian Bronze |
| Latch Faceplate | 1" Square Corner |
| Strike | Square Corner with reinforcing plate |
| Latch | 1" Throw |
| Bolt | Brass, tapered w/ security pin |
| Backset | Adjustable 2-3/8" or 2-3/4" |
| Cross Bore |
2-1/8" |
| Edge Bore | 1" |
| Door Thickness |
1.75" to 2.00" |
| BHMA Certification |
Grade 2 |
| Manufacturer's Warranty | 1 Year Electronic |
