Baldwin Reserve - TUB.CSR - Tubular Lever Set - Contemporary Square Rose - Optional Function - 260 - Polished Chrome - Grade 2

Baldwin Reserve - TUB.CSR - Tubular Lever Set - Contemporary Square Rose - Optional Function - 260 - Polished Chrome - Grade 2

In stock
SKU BLD-PV-TUB-CSR-260 NSID 43296
$65.97$117.78On Sale You save $51.81 (44%)
Get it shipped Today! Order within:
Function

Baldwin Tube Leverset with Contemporary Square Rose includes both sides of trim.

Passage Function: Baldwin's passage levers have no locking function and are free turning on both sides. These levers are perfect for a hallway or closet where no locking is necessary. Sometimes passage levers are used in conjunction with a deadbolt for an entrance or back door.

Privacy Function: Baldwin's privacy leversets are locked from the interior via a pin on the interior rosette. There is an emergency release hole on the exterior rosette. These privacy levers are perfect for a bathroom or bedroom where the ability to lock the door is desired but a keyed lock isn't necessary.

Entrance Function: Baldwin's single cylinder leverset has a keyed cylinder on the exterior and a lever with thumbturn on the interior. Unlocking and locking the lever is done by either a key on the exterior or via the thumbturn on the interior. Pair this keyed leverset with a Baldwin deadbolt for a complete back door or entrance solution.

Features:

  • Solid forged brass construction built to last a lifetime.
  • Baldwin 5-pin C-Keyway standard for keyed entry.
  • Versatility and Easy Installation:
    • Adjustable Latch for both 2-3/8" and 2-3/4" backset
    • Guide Post for Easy Installation
Call 1-800-878-6604 for Bulk / Dealer Pricing!
View full details

Details

  • Accommodates door thickness 1-3/8" to 2". Up to 2-1/2" thick door with service part kit (Part Number: 8BR0706).
  • 2-1/8" cross bore and 1" edge bore for latch.
  • Tested to exceed ANSI/BHMA Grade 2 security.
  • Shown with Contemporary Square Rose, can be customized with other Reserve roses.
  • Features easy-to-install spring assisted chassis for optimal operational strength.
  • Limited Lifetime Mechanical Warranty and Limited 25 Year Finish Warranty.

      • Specifications:

      Configuration
      		 Lever
      Function
      		 Passage, Privacy, Entrance
      Finish 260 - Polished Chrome
      Handing Non-Handed
      Backset Adjustable 2-3/8" or 2-3/4"
      Latch Faceplate
      		 Drive-In, Round Corner, Square Corner
      Cross Bore
      		 2-1/8"
      Edge Bore 1"
      Door Thickness
      		 1-3/4" to 2"
      Handle Length
      		 4.25 in
      Handle Projection 2.344 in
      Trim Height 2.5625 in
      Trim Width 2.5625 in
      Concealed Screws No
      BHMA Certification
      		 Grade 2
