Details
Specifications
| Lock Function | Storeroom |
| Handing | Non-Handed |
| Levers | 14 Lever – curved return |
| Door Thickness | 1-3/4" to 2 1/4" |
| Cylinder | 7-pin housing accepts all Best cores - Not Included |
| Rose | 3 1/2" Convex |
| Backset | 2 3/4" |
| Chassis | 2 1/16" diameter to fit 2 1/8" hole in door |
| Latchbolt | Solid brass 9/16" throw. Front 2-1/4" x 1-1/8" beveled |
| Strike | – Conforms to ANSI A115.2 for 1 3/4" doors (4 7/8" x 1 1/4" with curved lip). |
| Projection on Door | 2-3/4" when mounted on 1-3/4" door |
| Finish | 626 - Satin Chrome |
| Certifications |
ANSI/BHMA A156.2 Series— Grade 1 ANSI A117.1 Accessibility Code (ADA compliant) UL/cUL listed (3 hour) forsingle or double swinging doors Florida Building Code andMiami Dade County (WS option) compliant for hurricane resistance |
| Manufacturer Warranty | 10-Year Mechanical |
