Details
The Black Widow Features
|
Primary Features |
|
Portable Much lighter than most comparable key machines and includes a retractable carrying handle for convenient, one-handed portability. |
|
Flexible The only machine that we know of with native 12V power. This allows you to power your Black Widow using the standard 110V power cable (included), a 12V vehicle power adapter [TBW-CBL-2], or via our portable battery pack [TBW-POWER-PACK] *Please Note: Vehicle must be running to power your Black Widow with the 12V vehicle power adapter. |
|
Strong & Powerful The powerful 12,000 RPM brushless motor with a high-quality Japanese drive belt will keep your machine working strong for years to come. |
|
Clean No more key shavings all over your work area! A large protective screen/shield keeps it all out of your eyes and guided into the removable chip tray. |
|
Easy Touchscreen Interface Controlled wirelessly using the powerful optional tablet & stand, or feel free to use your own personal Android or iOS device. Designed with a super simple, professional, and friendly user interface. See the Software Features below. |
|
Interchangeable Jaws Includes a single, patented, 4-way “S1” jaw for almost all automotive keys, high security and edge-cut. Use the optional 2-way “S2” jaw for single-sided or double-sided edge-cut keys. No extra adapters or jaws to buy and swap like most other machines require. |
|
Organized Use the integrated storage compartment to keep all of your cutters, tracers, and other accessories safe and in one place. |
|
Personalized The mobile app includes a Favorites menu for fast access to frequently used keys and a Cut History screen showing your previous work, including key types, cuts, and notes. |
|
Continuous Improvements Developed by locksmiths in America, we continuously add new features, new key types, and optimizations at least once a month. |
|
Developed & Supported in America Developed by locksmiths in America, we continuously add new features, new key types, and optimizations. New software updates are normally released on a monthly basis. |
|
Software Features |
|
Easy and Effective Search Find your key type in 6 different ways: (1) vehicle search by year/make/model (2) keyword search using Ilco EZ or Silca key names (3) search by Triton/Black Widow card number (4) search by HPC Blitz card number (5) search by Instacode card number (6) use the Favorites menu for the fastest way to access your most commonly used keys. |
|
Favorites The Favorites menu allows you to add your most commonly used key types so you can reach the cutting screen in just two clicks. Use the same mobile device across multiple machines (including Tritons) to access your personalized Favorites. |
|
Cut History All of your work is saved in Cut History for easy reference, including key types and cuts, shown chronologically. You can delete individual records or add notes such as customer number, VIN, or invoice number for later search. Use the same mobile device across multiple machines to access your complete history. |
|
Custom Key Profiles Create your own custom key types directly in the system for new keys not yet in the database (not available for dimple keys). Use the same mobile device across multiple machines to access all custom key types. |
|
Decode by Photo Take a photo of your key to visually decode it yourself—great for non-conductive keys (aluminum, plastic) or worn keys. This mobile-only feature isn’t possible on machines with built-in touchscreens. |
|
Trace Duplication Copy unknown keys by specifying the type (single-sided edge-cut, double-sided edge-cut, laser-cut, internal, or tubular). The machine automatically traces the key’s shape to duplicate it accurately. |
|
Progressioning (Fill) Know some, but not all, of a key’s cuts? Enter what you know and the software generates possible missing cuts to create a working key. (Internet connection required) |
|
Comprehensive Key Code Database Converts most codes to cuts for automotive, commercial, and residential keys potentially eliminating the need for other code conversion software. (Internet connection required) |
|
Support for Decimals (Fractional Cuts) Use decimals for precision cutting or duplicating exact key measurements. Toggle decimals on or off to duplicate worn keys precisely or return them to factory specifications. |
|
Adjustable Cutting Depth Easily fine-tune cutting depth to fix thick webbing issues, especially common in Honda high-security keys, without needing shims. |
|
Choose Between Plunge or Contour Cutting Choose plunge cutting for a traditional look or contour cutting for faster performance. Both work perfectly; plunge cutting just makes the key look more “factory original.” |
|
Easy and FREE Wireless Updates Enjoy lifetime free updates. Since the machine uses a mobile app, updates can be installed automatically in the background without interruption. This preference needs to be set in your settings |
|
The Black Widow Specifications |
|
|
Motor Type |
Brushless Motor with Belt-Drive System |
|
Motor Rotation Speed |
12,000 RPM |
|
Dimensions |
10.5" W × 14" D × 12" H |
|
Net Weight |
32.9 lbs |
|
Working Temperature Range |
0–40°C / 32–104°F |
|
Working Humidity Range |
10–90% |
|
Warranty |
90-Days |
Recommended & Replacement Accessories
- Edge-Cut Commercial & Automotive Jaw [TBW-JAW-S2]
- Motorcycle & Vending Machine Tubular Jaw [TBW-JAW-S3]
- 6 & 8-Cut Tibbe Jaw for Ford and Jaguar [TBW-JAW-S4]
- 2.0mm Standard Replacement Cutter [TBW-TRC-01]
- 1.5mm Replacement Cutter for VW/Audi [TBW-TRC-05]
- Standard Dimple Cutter [TBW-TRC-3C]
- MTL 'Inside' Dimple Cutter [TBW-TRC-3D]
- MTL 'Outside' Dimple Cutter [TBW-TRC-3E]
- 2.0mm Aluminum & Plastic Key Cutter [TBW-TRC-06]
- 1.0mm Standard Replacement Decoder [TBW-TRD-1]
- 1.0mm Dimple Decoder [TBW-TRD-2]
- Commercial Keys Software Package [TBW-COM-SFT]
- Premium Android Tablet [7"] and Articulating Stand [TBW-TBLT-STD]
- Vehicle Power Adapter 12-Volt [TBW-CBL-2]
- Wall-Mounted Shield Holder [MAG-ACC-HLDR-4]
- Mesh Chip Tray Cover - multiple colors available [MAG-ACC-TRAY]
- Bench Mounting Kit [TBW-MNTKT]
Limited Manufacturer's Warranty
Lock Labs warrants the Black Widow key cutting machine in compliance with this certificate, in effect for 90-days from the date of purchase. In order to redeem the benefits provided to you by this warranty, this documentation must be provided in tandem with a verifiable proof of purchase, as issued by an authorized Black Widow distributor. This warranty covers the free repair or replacement of any parts deemed faulty as a result of imperfect manufacturing.
This warranty does NOT cover:
Damage or malfunctions caused by natural disasters or acts of God (lightning, fire, flood, earthquakes and other external causes).
Theft, misplacement, reckless, abusive, willful or intentional conduct associated with handling and use of the Black Widow.
Faulty installation, repair, or maintenance by anyone other than a Lock Labs authorized service provider.
Damage to or failure of unauthorized aftermarket upgrades or add-on accessories (This includes the electrical failure of the machine due to the usage of inferior or inefficient power inverters).
Consumer replaceable or consumable items, including but not limited to: cutting bits, tracers (decoders), T-wrenches (Allen wrenches), Allen-slotted threaded bolts, tip stop/calibration block, debris brush and AC power adapter.
Extreme environmental conditions (including extreme temperature or humidity) leading to problems such as external condensation, overheating and mold.
Usage outside of the permitted or intended uses, as described by the manufacturer.
Malfunctions caused by improper operation by machine operator.
Damage caused by insect infestation or rodents.
Covered products that have been reported as lost or stolen.
Any machine whose serial number has been altered, defaced or removed.
Any machine whose software has been modified or altered beyond the normal scope of use.
Damage that is secondary, or any damage that would be ordinarily covered under a primary insurance policy (e.g., car accident causes damage to the Black Widow).
Protection against any other act or result not covered by this plan.
Any resultant damage to the Black Widow that arises from one or more conditions described above.
Except for the above cases, all qualifying malfunctions are eligible for free service within the warranty period. To assure your request for service is handled efficiently, please contact Lock Labs customer service prior to sending us any product. We will issue you a Return Authorization Form that must be included when shipping your product to us. Failure to do so will result in service delays.
How to Obtain Service and Support
You may obtain service by accessing llwrc.com, or by calling Lock Labs at (888) 816-1046. Regular business hours are Monday through Friday, 8:30am to 5:00pm Pacific Standard Time.
To receive service or support, you agree to comply with each of the terms listed below:
You will provide a copy of this warranty and a copy of your purchase, exchange and service receipts, if requested.
You will provide, to the best of your ability, information about the symptoms and causes of your issues with the Black Widow.
You will respond to requests for information, including but not limited to: your product serial number, version of the software installed, any peripheral devices connected or installed on the Black Widow key machine, any error messages displayed, the actions which were taken before the Black Widow experienced the issue and the steps taken to attempt resolution to the issue.
You will follow instructions we give you, including but not limited to refraining from sending us products and accessories that are not subject to repair or replacement service (as listed above) and packing the Black Widow in accordance with the shipping instructions we will provide to you upon service agreement.
You will be required to sign a service order disclaimer or other service order terms to obtain repairs or a replacement device. This service order disclaimer or other service order terms do not form a part of this warranty, and are a separate legal document.
