Details
Specifications:
| System: | Linux Operation System |
| RAM: | 16G EMMC |
| Image Sensor: | 1/2.7" CMOS |
| Lens: | 4mm |
| Effective Pixel: | 2MP, 1920*1080 |
| Min. Lux: | Color 0.01Lux @F1.2 (ICR) B/W 0.001Lux @F1.2 |
| SNR: | ≥50db(AGC OFF) |
| WDR: | ≥80db |
| Facial Recognition Height: | 1.2 - 2.2, angle adjustable |
| Facial Recognition Distance: | 0.5 - 3 meters |
| Facial Recognition View angle: | Vertical ±30° |
| Recognize Time: | <500ms |
| Function: | Support 22400 faces database and 100000 records |
| Temp. Range: | 30-45 °C |
| Accuracy: | ±0.3 °C |
| Distance: | 0.3 - 0.8 meters |
| Response Time: | <300ms |
| Internal Interface: | RJ45 10M/100M Ethernet |
| Weigand Port: | Support input/output 26 and 34 |
| Alarm Output: | 1ch relay output |
| USB: | 1 USB port (can be connected to ID identifier) |
| Power Input: | 12VDC / 3Amp |
| Power Consumption: | 20 Watts Max |
| Working Temp: | 0°C ~ 50°C |
| Humidity: | 5 ~ 90%, no condense |
| Dimensions: | 154mm (W) * 89mm (H) * 361.4mm (L) |
