*Discontinued* Bolide - BC1536-AHN-12-24 - HDCVI / 5MP / 4MP / 2MP / Bullet Camera / Varifocal / 3.3-12mm Lens / Outdoor / IP66 / 40m IR / 12VDC - 24VAC Dual Voltage / White Finish
Out of Stock
SKU:
BOL-BC1536-AHN-12-24
NSID:
23403
- $221.38
-
- $221.38
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
BC1536-AHN-12-24
The new BC1536-AHN-12-24 supports 9 different video formats. Using the Quickswitch joystick built-in to the camera chord, the user can switch between AHD, TVI, CVI, and analog modes. After accessing the on-screen display via DVR or camera, the camera can be set to support 5MP, 4MP, and 2MP resolutions to make it the most supported HD over coax camera in the market.
Same as the BOL-BC1536-AHN but with Dual Voltage.
Features:
- 1/2.7" CMOS
- 3.3 – 12mm Varifocal Lens
- 5MP / 4MP / 2MP
- AHD / TVI / CVI / Analog
- IR Distance up to 40m
- 12VDC - 24VAC Dual Voltage
- Control Over Coax, OSD, Quickswitch
- $221.38
-
- $221.38
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
Description
xSpecifications:
| Image Sensor | 1 / 2.7” CMOS |
| Resolution | 2560 (H) x 1920 (V) 1920 (H) x 1080 (V) |
| Effective Pixels | 5MP / 4MP / 2MP |
| Focal Length | 3.3 – 12mm Varifocal Lens |
| IR Distance | 24pcs Flux IR Up to 130 Feet |
| Output Mode | AHD / TVI / CVI / Analog |
| Min. Illumination | Color: 0.1 Lux White / Black 0.1 Lux ( with IR LED On ) |
| AGC | Auto |
| WB | Auto |
| AES | NTSC: 1/60s ~ 1/10000s PAL: 1/50s ~ 10000s |
| D/N Conversion | ICR Mechanical Switch |
| Contrast | 10 Level Can Be Adjusted |
| Sharpness | 20 Level Can Be Adjusted |
| Saturation | 20 Level Can Be Adjusted |
| DNR | 15 Level Can Be Adjusted |
| Video System | NTSC |
| DWDR | ON/OFF |
| S/N Ratio | More than 48 dB |
| Storage Temp. | -40ºC ~ 140º C |
| Operating Temp. | -40ºC ~ 131º C |
| Power Supply | 12VDC - 24VAC Dual Voltage |
| Weight (lb) | 1.8 lbs |
Downloads:
