Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S
Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S
Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S
Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S
Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S
Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S
Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S

Bolide / Hybrid DVR / 32 Channel / Control Over Coax / 5MP Lite / Up To 1080P / 4K / 32TB HDD / SVR9532S

$1,078.40 $1,294.08
Availability: Available
Wishlist
  • Product SKU: BOL-SVR9532S
  • NSID: 23446
  • BOL-SVR9532S

    • 32-Channel Inputs
    • H.264 HD Over Coax
    • IP Hybrid DVR (Analog & IP)
    • AHD / TVI / CVI/ Analog Formats
    • Up to 8 Additional IP Cameras
    • Supports Up to 4K Cameras
    • 1080P Throughout 4K Output; HDMI, VGA
    • 4-Channel Audio In/ 1-Channel Audio Out
    • 4 Hard Drive Bay Up to 8TB each bay, 32TB max
    • Quick Connect



    $1,078.40
    Get it shipped
    Today!
    Order within
    00 Hrs
    00 Mins
    00 Secs

    Specifications:

    Record Bandwidth: 32Mbps IP recording, 128Mbps Max
    Record Resolution: Analog: 5MP Lite/4MP Lite/3MP/1080P Lite/720P/960H
    IP: 5MP/4MP/3MP1080P/720P
    Record Speed: Analog: 5MP: 11fps (each ch) 3MP: 8fps (each ch) 1080P: PAL: 15fps (each ch) 720P: PAL: 25fps (each ch)/NTSC: 30fps (each ch) 960H: PAL: 25fps (each ch)/NTSC: 30fps (each ch)
    IP: PAL: 25fps (each ch)/NTSC: 30fps (each ch)
    Video System: NTSC/PAL
    Operating System: Embedded Linux
    Video input/output: Analog: 32CH inputs/VGA& HDMI output
    IP: 8CH Input
    Composite: Up to 40 CH (Analog video + IP video)
    Audio Input/Output: 4CH inputs / 1 CH output (RCA)
    Alarm Input/Output: 8CH inputs /1CH output
    Max Decode Performance: 5MP: 16CH real-time
    Synchronous Playback:
    16CH
    Network Type:
    TCP/IP, P2P, 1 SATAHDD, up to 8TB
    Video Compression: H.264
    HDD: 4 SATA up to 32TB
    PTZ Control:
    RS-485, Control over Coax
    VGA / HDMI:
    1280x1024, 1440x900, 1280x720, 1920x1080, 1680x1050, 1600x1200, Lite 1944x1280
    Mobile Connect:
    Quick Connect allows mobile connection
    USB: 2x 2.0 USB for mouse/backup
    Voltage: 12VDC / 5 Amps
    Dimensions W x D x H: 378 x 326 x 66mm (14.9" x 12.8" x 2.6"in)



    Downloads:

    BOL-SVR9532S

    • 32-Channel Inputs
    • H.264 HD Over Coax
    • IP Hybrid DVR (Analog & IP)
    • AHD / TVI / CVI/ Analog Formats
    • Up to 8 Additional IP Cameras
    • Supports Up to 4K Cameras
    • 1080P Throughout 4K Output; HDMI, VGA
    • 4-Channel Audio In/ 1-Channel Audio Out
    • 4 Hard Drive Bay Up to 8TB each bay, 32TB max
    • Quick Connect


      Specifications:

      Record Bandwidth: 32Mbps IP recording, 128Mbps Max
      Record Resolution: Analog: 5MP Lite/4MP Lite/3MP/1080P Lite/720P/960H
      IP: 5MP/4MP/3MP1080P/720P
      Record Speed: Analog: 5MP: 11fps (each ch) 3MP: 8fps (each ch) 1080P: PAL: 15fps (each ch) 720P: PAL: 25fps (each ch)/NTSC: 30fps (each ch) 960H: PAL: 25fps (each ch)/NTSC: 30fps (each ch)
      IP: PAL: 25fps (each ch)/NTSC: 30fps (each ch)
      Video System: NTSC/PAL
      Operating System: Embedded Linux
      Video input/output: Analog: 32CH inputs/VGA& HDMI output
      IP: 8CH Input
      Composite: Up to 40 CH (Analog video + IP video)
      Audio Input/Output: 4CH inputs / 1 CH output (RCA)
      Alarm Input/Output: 8CH inputs /1CH output
      Max Decode Performance: 5MP: 16CH real-time
      Synchronous Playback:
      16CH
      Network Type:
      TCP/IP, P2P, 1 SATAHDD, up to 8TB
      Video Compression: H.264
      HDD: 4 SATA up to 32TB
      PTZ Control:
      RS-485, Control over Coax
      VGA / HDMI:
      1280x1024, 1440x900, 1280x720, 1920x1080, 1680x1050, 1600x1200, Lite 1944x1280
      Mobile Connect:
      Quick Connect allows mobile connection
      USB: 2x 2.0 USB for mouse/backup
      Voltage: 12VDC / 5 Amps
      Dimensions W x D x H: 378 x 326 x 66mm (14.9" x 12.8" x 2.6"in)
