*Discontinued* CodeLocks - KL1000 - Compact Digital Cabinet / Locker Lock - Optional Handing

*Discontinued* CodeLocks - KL1000 - Compact Digital Cabinet / Locker Lock - Optional Handing

Discontinued
SKU CDL-KL1000-PS-SG-LH NSID 25763
$90.17
Handing

CDL-KL1000

The KL1000 is easy to fit, taking just a few minutes to remove the existing cam lock and making an additional top fixing. KL1000 Classic can also be fitted to a locker or cabinet that does not have an existing locking device - just drill another hole. Once in place, the lock will perform up to 15,000 openings on just two AAA batteries. Access control without the need for keys.

Features:

  • Easy fit
  • 11 individual round buttons
  • 15,000 openings from 2 x AAA cells (supplied)
  • Battery override
  • Ideal for cabinets, lockers, cupboards, medical carts, data racks, safes
  • RAL color locks available on request, minimum order quantities apply
  • IP55 rated when used with the rubber door gasket - a separate part
  • Not suitable for a Chlorine environment
  • Use in offices / schools / warehouses / hospitals / care homes / nurseries / hotels / leisure facilities / the home
  • NetCode web-based code creation available (KL1000 NetCode)

View full details

Details

The KL1000 Classic has 4 code levels available:

  • 8 digit Master Code
  • 8 digit Sub-Master Code
  • 4 digit User Code
  • 6 digit Technician Code
FEATURE DESCRIPTION
Operations Up to 15,000 opening per 2 x 1.5 AAA batteries
Battery Override A 9-volt battery can be placed against external contacts
Low Battery Warning Red LED will flash on opening to indicate low battery
Functions Private and Public
Buttons 11 individual round buttons
Material Zinc Alloy
Finish Color Silver
Door Thickness Ready to fit doors up to 1” (25mm)
Memory Non-volatile memory will be retained
Installation Easy to install and program
Install Options right hand and left-hand models
IP55 Rated When used with rubber gasket (available separately)
Crank Cam Backset: 1 7 /16” (37mm) Overall Length: 1 3 /4” (45mm)
Flat Cam Backset: 1 1 /4” (32mm) Overall Length: 1 9 /16” (40mm)
Slam Latch Retrofit to existing KL1000 locks or purchase for new locks. Easy shutting.
