CodeLocks - KL1050 - RFID Electronic Kit Lock - Up to 1/4" Door Thickness - Locker Lock - No Pre-Assembly - Silver
- $98.87
-
$154.50 - $98.87
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
CDL-KL1050
The KL1050 RFID KitLock offers functions for single users (Private Function) and short term use by multiple users (Public Function). The KL1050 RFID can be easily fitted to replace an existing cam lock, or to fit to a new locker or cabinet that does not have an existing locking device. The lock will perform up to 15,000 openings on just two AAA batteries.
- with Interchangeable Spindles to fit 1/4” - 1" Thick Door.
Features:
- Supports MIFARE® Classic
- Master User Card
- Technician Card
- Public Pairing Feature
- Any orientation
- Up to 15,000 operations from 2 x AAA batteries (supplied)
- Battery override
- Slam latch accessory available
- All parts / fixings / templates included
Private Function
This is the most common function and used where the same code will be repeatedly used, e.g. a pupil in a school or an employee with the same locker in the workplace.
Public Function
In this function the KitLock operates with a single User Code. The user enters their own personal four-digit code. This locks the lock. The same code is entered once only to open the lock before being erased and ready for the next new user. This function is used for short term, multi occupancy applications, e.g. a locker in a leisure center.
Specifications:
| Brand |
KitLock by Codelocks |
| Battery Override | A 9 volt PP3 battery can be placed against external contacts |
| Code Change Method | Keypad (On Door) |
| Buttons | 2 x 5 + Programming |
| Door Thickness |
Ready to fit doors up to 1" (25mm) |
| Finish |
Silver |
| Functions |
Private, Public |
| Keypad | 11 individual round buttons |
| Lock Dimensions | 5 3⁄8" (136mm) x 11⁄16" (28mm) x 15⁄16" (33mm) |
| Low Battery | Red LED will flash on opening to indicate low battery |
| Latch Type |
Cam |
| Memory |
Non-volatile memory will be retained |
| Operations |
Up to 15,000 opening per 2 x 1.5 AAA batteries |
| Power | 2x AAA |
| Orientation |
Vertical |
| Suitable For |
Internal |
| User Levels |
Master, Technician |
| User Types |
Card |
