Details
Functions:
Codelocks NetCode® Technology
This function allows temporary access. Create time-sensitive codes via the Codelocks Connect Portal or your own application with Codelock's simple API (application programming interface).
Private Function
This is the most common function and used where the same code will be repeatedly used, e.g. a pupil in a school or an employee with the same locker in the workplace.
Public Function
In this function the KitLock operates with a single User Code. The user enters their own personal four-digit code. This locks the lock. The same code is entered once only to open the lock before being erased and ready for the next new user. This function is used for short term, multi occupancy applications, e.g. a locker in a leisure center.
Types of NetCode
Five types of NetCode are available:
- Short-term multi-use codes with durations from 1 to 12 hours and 1 to 7 days
- Short-term single-use codes with durations from 1 to 12 hours and 1 to 7 days
- Medium-term codes with durations from 1 to 21 days + 28 days
- Long-term codes that work for periods of up to 1 year
- Codes that will expire on a particular date
Additional NetCode Features
- New NetCode Blocks Previous NetCode
- This feature automatically blocks the last used NetCode when a new NetCode is entered.
- Mode Restrictions
- Choose which types of NetCode to support. This is a useful feature if the number of potentially available NetCode modes needs to be reduced.
- Block a NetCode
- Block a NetCode directly on the lock using either the Master Code or another valid NetCode.
- Person User Code
- Allow a NetCode user to create a personal 4 digit number that retains the same validity period as their originally allocated NetCode.
Specifications:
| Brand |
KitLock by Codelocks |
| Battery Override | A 9 volt PP3 battery can be placed against external contacts |
| Code Change Method | Keypad (On Door) |
| Buttons | 2 x 5 + Programming |
| Door Thickness |
Ready to fit doors up to 1" (25mm) |
| Finish |
Silver |
| Functions |
Private, Public, NetCode® |
| Keypad | 11 individual round buttons |
| Lock Dimensions | 5 3⁄8" (136mm) x 11⁄16" (28mm) x 15⁄16" (33mm) |
| Low Battery | Red LED will flash 3 times before unlocking |
| Latch Type |
Cam |
| Memory |
Non-volatile memory will be retained |
| Operations |
Up to 15,000 opening per 2 x AAA batteries |
| Power | 2x AAA |
| NetCode | Standard (Multi Use), Standard (Single Use), Rental 365, Rental 1 - 21 Days |
| Orientation |
Vertical, Left Handed, Right Handed |
| Suitable For |
Internal, External |
| User Levels |
Master, Sub Master, Technician, User |
| User Types |
Code, NetCode |
