Details
| GENERAL DATA | |
| Height (inch) (in) | 6.3 |
| Width (inch) (in) | 4.53 |
| Depth (inch) (in) | 0.87 |
| Product weight (oz) (oz) | 17.64 |
| Product color | White RAL9003 |
| Type of finishing materials | ABS |
| Wall-mounted | Yes |
| COMPATIBLE SYSTEMS | |
| Audio/video Simplebus 2 with power supply art. 4888CU | Yes |
| Audio/video Simplebus 2 with power supply art. 1210/1210A | Yes |
| Simplebus 2 audio/video kit with power supply art. 1209 | Yes |
| DISPLAY | |
| Display size (") | 4.3 |
| Aspect Ratio | 16:9 |
| Resolution (pixels) | 480x272 |
| AUDIO FEATURES | |
| Microphone | 6mm (Ø), Omnidirectional |
| Loudspeaker | 36mm (Ø), 40 Ohm, 1W |
| Technologies implemented | Full-Duplex |
| ELECTRICAL CHARACTERISTICS | |
| Type of power supply | Power supply from video door entry bus |
| Supply voltage | 22÷34 VDC (Bus) |
| Absorption in stand-by (W) | 0.05 |
| Maximum absorption (W) | 8.8 |
| HARDWARE FEATURES | |
| Type of buttons | Capacitive |
| Service buttons | Lock-release, Answer, Silent (Privacy) |
| No. of programmable buttons for additional functions |
2 (5 with accessory art. 6734W) |
| Clamps | L L CFP1 CFP2 |
| Removable terminals | Yes |
| Number of inputs (n°) | 1 |
| SETTINGS | |
| Loudspeaker volume | Yes |
| Microphone volume | Yes |
| Ringtone volume | Yes |
| Screen brightness control | Yes |
| Screen contrast | Yes |
| Screen colour | Yes |
| ENVIORNMENTAL | |
| IP protection rating | IP30 |
| Operating temperature (°F) | 41 ÷ 104 |
| Operating humidity (RH max) (%) | 25 ÷ 75 |
| Environmental class | I |
| CE certifications | RoHS II - 2011/65/UE (EN IEC 63000:2018), EMC 2014/30/UE (EN 61000-6-1:2007 , EN 61000-6 3:2007+A1:2011) |
| GENERAL FEATURES | |
| Door opening on call (Doctor) | Yes |
| Door opener | Yes |
| Self Activation | Yes |
| CPS call | Yes |
| Intercom calls | Yes |
| Actuator control | Yes |
| Multiple address | Yes |
| Outside door call input | Yes |
| Sending alarm calls | Yes |
| Silent mode (Privacy) | Yes |
| Automatic answer (handsfree) | Yes |
| Door open signaling | Yes |
| Customisable ringtone | Yes |
