*Discontinued* COMPX - C8086 - Disc Cam Lock 1-3/4in - Bright Nickel Finish

*Discontinued* COMPX - C8086 - Disc Cam Lock 1-3/4in - Bright Nickel Finish

Discontinued
SKU COMX-C8086-KAC346A-14A NSID 90817
$11.49

The CompX National C8086 Series Disc Tumbler Cam Lock is engineered for high durability and versatile access control. This heavy-duty commercial-grade lock provides robust security for cabinets, enclosures, drawers, and access panels. It comes standard with a sleek, corrosion-resistant Bright Nickel (14A) finish that seamlessly complements modern office, laboratory, or industrial furniture.

Features:

  • Premium Security: Equipped with a dependable 5-disc tumbler mechanism designed to resist picking and standard bypass methods
  • Keyed Alike Comfort: Pre-configured to key code C346A, minimizing key clutter for multi-enclosure facilities.
  • Flexible Key Rotation: Allows for either 90° or 180° cam rotation depending on the internal stop washer configuration used during installation.
  • Key Retention & Removal: Engineered for flexible operation; the key remains secure while turning, but can be easily removed in both the fully locked and unlocked positions
  • Industrial Finish: Finished in a professional, polished Bright Nickel plating (Color Code 14A) to prevent wear, scratching, and rust.
View full details

Details

Specifications:

Part Number  C8086-KAC346A-14A / C8060-KA346A-14A
Lock Type  Mechanical Disc Tumbler Cam Lock
Keying Style  Keyed Alike (KA)
Key Code Replacement  C346A (Uses standard D8785 Key Blanks)
Material  Heavy-Duty Die-Cast Steel Core & Hardware
Finish  Bright Nickel (14A)
Required Mounting Hole  3/4" 919mm) standard bore diameter
Core Face Diameter  7/8"
Manufacturer  CompX
Applications Office Desks, Filing Systems, Retail Showcases, Credenza Drawers, Jewelry Cases, Storage Cabinets, Medical, Lab, pharmaceutical carts, industrial electrical boxes, utility panels, metal enclosures.



Package Includes:

  • 1x CompX national disc tumbler cam lock cylinder
  • 2x Matching C346A cut keys
  • 2x Interchangeable Cams (Straight & Offset variants for flexible latching depth)
  • 1x Complete Mounting Hardware Kit (Includes mounting nut, trim washer, and wood surface spur washer.
