*Discontinued* Schlage - ND92PD - Commercial Lever Set - Athens Lever - Entrance - Satin Chrome - Grade 1

*Discontinued* Schlage - ND92PD - Commercial Lever Set - Athens Lever - Entrance - Satin Chrome - Grade 1

Discontinued
SKU SCH-ND92PD-ATH-626 NSID 65387
$486.14$583.37On Sale You save $97.23 (17%)


The Schlage ND is extremely versatile and is regularly used in healthcare, education, government, office, retail, and other commercial applications. With 31 mechanical functions, the ND's range spans from simple (non-locking passage) to complex (double-cylinder security) to specialized (school time-out lock). Because the ND uses an ANSI 161 door prep, commonly used across cylindrical locks, it is ideal for both new construction and retrofit applications.

Features

  • Significantly exceeds ANSI/BHMA A156.2 requirements for Grade 1 cylindrical locks
  • Supports standard, SFIC, and FSIC cylinder formats
  • Fire Rated for 3 Hours
  • ATH - Athens Lever Style
  • Support for 10 non-Schlage cores
View full details

Details

Specifications

    Lock Function F109 - Entrance - Inside lever always free for immediate egress. Keyed entry on the exterior.
    Handing Non-Handed
    Door Thickness 1-5/8" to 2-1/8" (41 to 54 mm)
    Faceplate Size 1-1/8" x 2-1/4"
    Cylinder 6-Pin Patented Everest 29
    Keyway Schlage C - KD
    Backset 2 3/4" (70 mm) only
    Bolt 1/2" throw via Oil Impregnated Stainless Steel
    Latch
    		 1"
    Lever ATH - Athens Style
    Material Stainless Steel / Zinc
    Rose
    		 3-7/16"
    Strike 1-1/4" x 4-7/8" x 1-3/16"
    Finish 626 - Satin Chrome
    Certifications
    		 ANSI/BHMA A156.2-2003, Exceeds 800,000 ANSI Cycles, Meets FF-H-106C Series 161, MEA Certification, Grade 1, Fire Rated for 3 Hours
    Manufacturer Warranty 10 years mechanical, 1 year wired electrified


    Downloads
