Details
Specifications
| Lock Function: | Storeroom F07 |
| Handing | Field Reversible |
| Door Thickness | 1 3/4" (44 mm) |
| Cylinder | No Cylinder - Lock Body Only |
| Backset | 2 3/4" (70 mm) |
| Strike | Wrought brass, bronze or stainless steel, ANSI straight lip standard, 4-7/8" (124mm) x 1-1/4" (32mm) x 1-1/8" (29mm) lip to center |
| Cylinder | Brass, 6-pin, L4 keyway, 0-bitted standard |
| Latchbolt | 2-piece mechanical with anti-friction insert, 5/8" (16mm) x 1" (25mm) x 3/4" (19mm) throw |
| Deadbolt | One-piece stainless steel, 19/32" (15mm) x 1-1/4" (32mm) x 1" (25mm) throw |
| Material | Stainless Steel |
| Lock Face Size |
8" x 1-1/4" |
| Spacing | Knob/Lever to cylinder: 3-5/8" (92 mm); knob/lever to thumbturn: 2 -7/16" (62 mm) |
| Fire Rated | 3 Hours |
| Certifications |
ANSI/BHMI Certified A156.13, Grade 1, UL/cUL Listed |
| Manufacturer Warranty | 10 Year Limited |
