Details
Specifications:
| Construction: | Heavy-gauge Steel |
| Function: | F05 - Classroom |
| Door Thickness: | 1-3/4" (44mm) standard |
| Backset: | 2-3/4" |
| Handing: | Factory Handed, But quickly reversible |
| Strike: | ANSI straight lip 4-7/8" x 1-1/4" x 1-1/8" lip to center |
| Deadbolt: | One-piece stainless steel 1" Throw |
| Cylinder: | Brass 6-Pin GA Keyway |
| Keys Included: | 2 |
| Latch bolt: | 2-piece mechanical with anti-friction insert, 5/8"x1"x 3/4" throw |
| Trim: | Lever: Cast Escutcheon: Wrought |
| Lockcase: | Heavy-gauge steel, 5-7/8"x4"x15/16" |
| Certifications: | ANSI/BHMA Certified A156.13 Series 1000, Grade 1, Meets A117.1 Accessibility Code. |
| Manufacturer's Warranty: | 10 Year limited warranty |
