Details
Specifications
| Electrical |
|
| Input | 120 VAC, 60 Hz |
| Output | 24 VAC (±5%), 5000 mA |
| Environmental | |
| Operating Temperature | –10 °C to +40° F (14 °F to 104 °F) |
| Operating Humidity | 30% to 85%, Relative |
| Physical Properties | |
| Dimensions (L x W x H) | 120.0 mm x 102.0 mm x 80.0 mm (4.72 in. x 4.02 in. x 3.15 in.) |
| Installation Mode | Plane Installation |
| Color | Black |
| Input Plug | 2-pin North American Plug |
| Cord Lengths | Input: 1 m (3.28 ft) Output: AWG16 x 2C; 0.75 m (2.46 ft) |
| Certifications | |
| Safety |
CE, UL, CCC |
