Technical Specification
| System | |
| Main Processor | Industrial-grade Embedded Processor |
| Operating System | Embedded LINUX |
| Audio and Video | |
| IP Camera Input | Four (4) Channels |
| Audio | Input: One (1) Channel, RCA Output: One (1) Channel, RCA |
| Analytics+ Recording | |
| Perimeter Protection - Channels | Four (4) |
| Perimeter Protection - Search | By channel, time, event type |
| SMD+ - Channels | Four (4) |
| SMD+ - Search | By target classification (human or vehicle) |
| Display | |
| Interface | One (1) HDMI One (1) VGA |
| Native Output Resolution | 3840 x 2160, 1920 x 1080, 1280 x 1024, 1280 x 720 |
| Maximum Decoding | Two (2) Channel of 8 MP at 30 fps Four (4) Channels of 4 MP at 30 fps |
| Multi-screen Display | 1/4 |
| On-screen Display | Camera Title, Time, Camera Lock, Motion Detection, Recording |
| Recording | |
| Video Compression | Smart H.265+, H.265, Smart H.264+, H.264, MJPEG |
| Audio Compression | PCM, G.711A, G.711Mu, G.726 |
| Supported IP Camera Resolution |
8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, D1 |
| Maximum Incoming Bandwidth | 160 Mbps |
| Record Mode | Manual Recording; Alarm Recording; SMD Recording; Smart Recording |
| Video Detection and Alarm | |
| Alarm Input | Four (4) Channels |
| Relay Output | Two (2) Channels |
| General Alarms | Motion detection, privacy masking, video loss, scene changing, PIR alarm, IPC external alarm |
| Anomaly Alarms | Camera disconnection, storage error, disk full, IP conflict, MAC conflict, login locked, and cybersecurity exception |
| Analytics+ Alarms | Face detection, perimeter protection (intrusion and tripwire), IVS, people counting, heat map, and SMD alarms |
| Alarm Actions | Recording, snapshot, audio, buzzer, log, preset, and email |
| Playback and Backup | |
| Sync Playback | 1/4 |
| Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to 1 second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Backup Selection, Digital Zoom |
| Backup Mode | USB Device, Network |
| Network | |
| Ethernet | One (1) RJ-45 Port (10/100/1000 Mbps), Self-adaptive |
| PoE | Four (4) Ports (IEEE802.3af/at) |
| Network Function | HTTP; HTTPS; TCP/IP; IPv4/IPv6; UPnP; SNMP; RTSP; UDP; SMTP; NTP; DHCP; DNS; IP Filter; DDNS; FTP; Alarm Server; IP Search (Support Dahua IP camera; DVR; NVS); P2P; Auto register |
| Maximum User Access | 128 Users |
| Mobile Operating System | IOS, Android |
| Browser | Chrome, IE 9 or later |
| Interoperability | ONVIF Profiles S,T,G; CGI, SDK |
| Storage | |
| Internal HDD | Two (2) SATA III Ports, Up to 2 TB |
| HDD Mode | Single |
| Auxiliary Interface | |
| USB | Two (2) USB 2.0 Ports |
| Electrical | |
| Power Supply | 53 VDC, 1.36 A |
| NVR Power Consumption | < 10 W, without HDD |
| Total PoE Budget | 25.5 W single port, 36 W total |
| Construction | |
| Dimensions | 375.0 mm x 282.90 mm x 53.0 mm (14.76 in. x 11.14 in. x 2.09 in.) |
| Certifications | EN, UL, CAN/CSA, FCC CFR |
| Manufacturer's Warranty | 5 Years |
