Details
Specification
| System | |
| Main Processor | Dual-core Embedded Processor |
| Operating System | Embedded LINUX |
| Audio and Video | |
| IP Camera Input | Four (4) Channels |
| Display | |
| Interface | One (1) HDMI One (1) VGA |
| Resolution - HDMI | 3840×2160, 1920×1080, 1280×1024, 1280×720 |
| Resolution - VGA | 1920×1080, 1280×1024, 1280×720 |
| Maximum Decoding | One (1) Channel of 8 MP at 30 fps Four (4) Channels of 1080p at 30 fps |
| Multi-screen Display | 1/4 |
| OSD | Camera title, Time, Camera lock, Motion Detection, Recording |
| Recording | |
| Compression | Smart H.265+, H.265, Smart H.264+, H.264 |
| Supported IP Camera Resolution |
8 MP, 6 MP, 5 MP, 4 MP, 3 MP, 1080p, 720p, D1, CIF (The recording rate is dependent on the maximum resolution and frame rate of the connected IP camera.) |
| Maximum Incoming Bandwidth | Wired Camera Connection: 80 Mbps Wireless Camera Connection: 24 Mbps |
| Bit Rate | 16 Kbps to 20 Mbps per channel |
| Record Mode | Manual, Schedule (Regular, Continuous), Motion Detection, Stop |
| Record Interval | 1 to 120 minutes (default: 60 minutes) Pre-record: 1 to 30 s, Post-record: 10 to 300 s |
| Video Detection and Alarm | |
| Trigger Events | Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
| Video Detection | Motion Detection, MD Zones: 396 (22 × 18), and Tampering |
| Playback and Backup | |
| Sync Playback | 1/4 |
| Search Mode | Time /Date, Motion Detection, and Exact Search (accurate to one second) |
| Playback Function | Play, Pause, Stop, Rewind, Fast Play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode | USB Device, Network |
| Network | |
| Interface | One (1) RJ-45 (10/100 Mbps) Port |
| Wireless | IEEE 802.11b/g/n, 2.4 GHz |
| Network Function | HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search (Support for Dahua IP cameras, DVRs, NVS) |
| Maximum User Access | 128 Users |
| Mobile Operating System | IOS, Android |
| Interoperability | ONVIF 2.4, CGI |
| Storage | |
| Internal HDD | One (1) SATA III Port, up to 6 TB capacity (ships with a pre-installed 2 TB HDD) |
| HDD Mode | Single |
| Auxiliary Interface | |
| USB | Two USB 2.0 Ports (One Front Panel, One Rear Panel) |
| Electrical | |
| Power Supply | 12 VDC, 2 A |
| Power Consumption | < 6.6 W (without HDD) |
| Construction | |
| Dimensions | Compact 1U, 260.0 mm x 247.40 mm x 198.20 mm (10.24 in. x 8.8.9 in. x 7.80 in.) |
| Certifications | UL, EN, FCC CFR, ANSI |
| Warranty | 5 Years |
