Details
Specifications
| System | |
|---|---|
| Main Processor | 8 Bit |
| Read | |
| Read Format | 13.56MHz |
| Read Range | 1cm–3cm (max.) |
| Reading time | <0.1s |
| Function | |
| Tamper Alarm | Yes |
| Interface | |
| To Controller | RS485, Wiegand34 (Wiegand 26 optional) |
| General | |
| Keypad | 12Keys (0-9,*,#) |
| LED Indicator | Yes |
| Beep Tone | Buzzer |
| Ingress Protection | IP55 |
| Power Supply | 9V–15V DC/100mA |
| Operating Temperature | -30°C to +60°C |
| Working Humidity | ≤95% |
| Dimension (W×D×H) | 135 x 47.5 x 16mm |
| Weight | 0.18kg |
| Working Environment | Outdoor |
| Certificates | |
| CE | Yes |
| FCC | Yes |
Downloads
Data Sheet
Installation
Technical Drawing
