Details
Technical Specifications
| Video | |
| Transmission Signal | One (1) Channel |
| Category Type | UTP CAT5E/6 |
| Transmission Distance, maximum | HDCVI, TVI, AHD: 720p: 400 m (1312.34 ft) 1080p: 250 m (820.21 ft) 4 MP, 6 MP, 8 MP: 200 m (656.17 ft) |
| Video Transmission Properties and Ports | |
| Coaxial Video Connector | BNC-M |
| Connection Way | RJ45 |
| Compatible Format | HDCVI, AHD, TVI, CVBS |
| Resolution | 720p, 1080p, 4 MP, 5 MP, 6 MP, 8 MP |
| Protection | |
| ESD | 1a contact discharge electricity level 3 1b air discharge electricity level 3 Per: IEC61000-4-2 |
| UTP Cable Connector | 2 KV (different-mode), 4 KV (common-mode), per IEC1000-4-5 |
| Impedance | |
| BNC Male | 75 Ω |
| UTP Cable | 100 Ω |
| Physical Properties | |
| Shell | ABS |
| Color | Black |
| Dimensions | 6.84 in. x 0.77 in. x 0.80 in |
