*Discontinued* Dahua / Intercom Outdoor Station / 24 VDC Power Adapter / 5 Year Warranty / DH-ADS-110DL-19-1
Out of Stock
SKU:
DH-ADS-110DL-19-1
NSID:
28102
- $25.19
-
- $25.19
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
DH-ADS-110DL-19-1
Dahua's 24 VDC, 3 A Power Adapter For Dahua PoE Switch.
Features:
- Supports 100 VAC to 240 VAC Wide-range Voltage Input
- 24 VDC, 3 A Power Output
- CE, UL, EAC, RCM Certification
- Compatible with VTNS1060A Network Power Supply and VTNC3000A Two-wire Network Controller
- For VTO1210C-X-S outdoor station
- Five-year Warranty (for products sold through authorized Dahua Dealers)
- Become a registered dealer of Dahua
- Call 1-800-878-6604 for Dealer Prices!
- $25.19
-
- $25.19
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
Description
x
Technical Specification:
| Power Input | |
| Input Voltage, Nominal | 100 VAC to 240 VAC, 50/60 Hz |
| Input Voltage Range | 90 VAC to 264 VAC, 47 /63 Hz |
| Input Current | ≤ 1.5 A-rms at 100 to 240 VAC at full load |
| Efficiency | ≤ 1.5 A-rms at 100 to 240 VAC at full load |
| Inrush Current (Cold Start) | Input fuse operational under cold start at 115/230 Vrms |
| Leakage Current | 3.5 mA, maximum (264 V, 50 Hz) |
| Certifications | |
| Safety | IEC 60950-1:2005+A1+A2 AS/NZS 60950.1:2011 Inc A1 GMA-501915-EA |
| Electromagnetic Compatibility (EMC) | FCC CFR 47 Part 15 subpart B ANSI C63.4 - 2009 EN 55022:2010, EN 55024:2010+A1:2015, EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, IEC 61000-4-2:2008, |
| Power Output | |
| Output Voltage, Nominal | 24 VDC |
| Output Voltage Adjust Range | 22.8 to 25.20 VDC |
| Line Regulation | ± 2% |
| Residual Ripple (PARD) 20 MHz BW | 300 mVpp (Input Voltage: 115 V to 230 V) |
| Output Current | 3 A, maximum |
| Rise Time | 10% to 90%, ≤ 50 ms at 100 V to 240 V Input/Output, maximum load |
| Hold-up Time | 10 ms, typical, at 115 VAC Input 20 ms, typical, at 230 VAC Input |
| Dynamic Load Response | |
| Condition | Load step from 20% to 80% to 20% R/S: 0.10 A/uS |
| Transient Response Recovery Time | ≤ 30 ms |
| Result | ±5%, Dynamic Voltage |
| Environmental | |
| Operating Temperature | 0° C to 40° C (32° f to 104° F) |
| Operating Humidity | 10% to 90% RH |
