Details
Specifications
| Camera | |
|---|---|
| Image Sensor | 1/3" 2.0MP CMOS Sensor |
| Image Resolution | 1920x1080 |
| Effective Pixels | 2.0MP |
| TV System | PAL/NTSC |
| Electronic Shutter | 1/10s~1/100,000s |
| S/N Ratio | ≥50dB |
| Min. Illumination | 0.05Lux@ (F2.0, AGC ON), 0LUX with IR |
| Scanning System | Progressive Scan |
| Lens | |
|---|---|
| Lens |
Board Lens 4mm/F2.0 |
| FOV | H: 73.9°, V: 40° D: 86° |
| Lens Type | Fixed |
| Night Vision | |
|---|---|
| Infrared SMD LED | 10µ x 15 PCS |
| Infrared Distance | 20m |
| IR Cut Filter | Yes |
| IR Status | Under 10 Lux by CDS |
| IR Power On | CDS Auto Control |
| Day & Night | Auto (ICR) / Color / B&W |
| Camera Features | |
|---|---|
| OSD Menu Language | Support |
| White Balance | Auto |
| Gain Control | Auto |
| UTC | Support |
| General | |
|---|---|
| Housing |
Plastic |
| Operation Temperature | -20°C ~ 60°C |
| Working Humidity | 10% ~ 90% |
| Power Source |
DC12V±10%, 250mA |
| Dimensions |
100 x 100 x 85mm |
| Weight |
≤190g |
Dimensions (mm)
Downloads
Data Sheet Installation Guide
