Details
Specifications
| CONSTRUCTION | |
|---|---|
| Conductors | 24 AWG solid bare annealed copper |
| Jacket | Flame-Retardant PVC |
| Insulation | Polyolefin |
| Rip Cord | Applied longitudinally under jacket |
| Color Code | Pair 1: Blue-White/Blue Pair 2: Orange-White/Orange Pair 3: Green-White/Green Pair 4: Brown-White/Brown |
| Finish | White |
| Physical Data |
CMR (Non-Plenum) |
|---|---|
| Nominal Cable Diameter (in) | 0.210 |
| Nominal Cable Weight (lbs/1000 ft) | 26 |
| Minimum Bend Radius (in) | 1.0 |
| Maximum Pulling Force (lbs) | 25 |
| Temperature Rating (˚C) | Installation: -10 to +60 Operation: -40 to +75 |
| Electrical Characteristics | |
|---|---|
| DC Resistance (max) Ohms/100 m (328 ft) @ 20˚C |
9.38 |
| DC Resistance Unbalance (max) Individual Pair % |
4.00 |
| Delay Skew (max) ns/100 m |
45 |
| Nom. Velocity of Propagation % Speed of Light |
70 |
| Characteristic Impedance Frequency (f): 1-100 MHz |
Ohms 100 ± 15 |
| Applications & Compliances |
|
|---|---|
| Applications | IEEE 802.3: 1000 BASE-T, 100 BASE-TX, 10 BASE-T, PoE, PoE+ CDDI, Token Ring, ATM Broadband and Baseband Analog Video |
| Standard Compliances | ANSI/TIA 568-C.2 NEC/CEC Type CMX OUTDOOR-CMR UL 444 Sunlight-Resistant UL 444 RoHS Compliant Directive 2011/65/EU ANSI/TIA 862 (Building Automation) ICEA S-100-685 ICEA S-90-661 ISO/IEC 11801 Ed. 2.0 (Class D) Telcordia GR-3164 Telcordia GR-3164 Severe Cold Impact |
