Details
Specifications:
|
Construction: |
All metal cast front housing; force-resistant, clutch-protected exterior thumbturn |
|
Numeric Keypad: |
Vandal resistant, solid metal pushbuttons |
|
Handing: |
Field reversible |
|
Latch: |
1" (25 mm) tubular deadbolt ½" (13 mm) deadlocking latch ⅝" (16 mm) rim deadlocking latch |
|
Backset: |
2⅜" (60 mm) backset |
|
Finish: |
Satin Chrome 26D (626) |
|
Strike: |
Models 7102 and 7108: Flat deadbolt strike plate Model 7104: Curved lip strike plate Model 7106: Box strike for in-swing doors and flat strike for out-swing doors |
|
Minimum Stile Required: |
4" (102 mm) |
|
Installation: |
1⅜" (35 mm) diameter through bore 1" (25 mm) diameter cross bore ¾" (19 mm) through bore 2 x ¼" through bores |
|
Door Thickness: |
1⅜" (35 mm) to 2¼" (57 mm), wood or metal |
|
Durability: |
Weather resistant |
|
Warranty: |
1-year warranty |
|
Finish: |
Black |
