Details
Specifications
| Function | Passage - Both Levers Always Unlocked |
| Finish | 626 - Satin Chrome |
| Screws | Wood or metal doors |
| Door thickness | 1 3⁄8" to 2" |
| Backset | 2 3⁄4" |
| Lever Style | Dane |
| Handing |
Non-handed |
| Rose | 3-1/4" diameter |
| Latches | 1⁄2" bolt projection |
| Strike | Square corner 1-1/4" x 4-7/8" ANSI ASA Strike |
| Door Preparation | 2-1/8" diameter for bore, 1" diameter latch bore. Fits standard 161 door prep. |
| Fire Rated | UL/ULC listed for 3 hour fire door |
| Certifications | Certified ANSI/BHMA A156.2, Series 4000, Grade 2, UL Listed |
| Manufacturer's Warranty | Limited Lifetime |
