Details
Specifications:
| Door thickness | 1-3/4" (44mm) - 1-7/8" (47.6mm) standard |
| Function | Latch bolt operated by knob/lever from either side. Dead bolt projected by key from outside and turn from inside. Operating inside knob/lever retracts both bolts and unlocks outside. |
| Backset | 2-3/4" (70mm) |
| Strike | Brass or stainless steel. Meets ANSI AII5.1 for frame preparation. Strike is non-handed |
| Dead Bolt | 1" throw, stainless steel with two 13⁄16" diameter hardened steel, free-turning, saw-resistant roller |
| Cylinder | SFIC Less Core Prep |
| Case | Cold formed steel, zinc dichromate plated, .090” thick. Optional lead wrapping available |
| Handing | Left Handed or Right Handed |
| Keyways | Falcon “G” keyway standard on standard cylinder. “A” keyway standard on I/C cylinder. |
| Fire Rating |
“A” Label 3 Hour Fire Doors Positive Pressure Rated |
| Certifications | ANSI A156.13, Grade 1, UL10B, UL10C |
