Details
Specifications:
| Construction: | Zinc Alloy |
| Function: | Finger Print, PIN Code, Key Card, Bluetooth |
| Fits: | Wood and Metal Doors |
| Door Width: | 1.18" - 2.95" |
| Door Thickness: | 1.38" - 2.16" |
| Finger Print Capacity: | 99 Sets |
| PIN Code Capacity: | 99 Sets |
| Available Password Digits: | 6-12 Valid Characters |
| Finger Print Reader: | FPC Reader |
| Fingerprint Collection: | Semiconductor Collector |
| FP Collection Time: | <0.5 sec. |
| Key Card: | MF1 |
| Card Read Distance: | 5-20mm (0" - 1") |
| USB: | 1x USB Charger Included |
| Low Battery Indicator: | < 4.8V |
| Working Temp: | -20C - 60C |
| Working Humidity: | 10%~95% |
| Power Consumption: | 150mA |
| Supply Voltage: | 6V DC |
| Power Supply: | 4 AAA Batteries |
| Emergency Power Supply: | 5V Micro USB |
| Dimensions: | 9.21" x 2.5" 0.71" |
Downloads:
Specifications
Remote Specifications
- Part Number
- R750-04, G750-BLK, G750
Downloads
Notes
Note: This is a Euro style mortise lock ...it is designed for use in European and South American markets
