Details
Specs
| Packaging |
|
|---|---|
| Notes |
|
| Certifications |
|
| Fastener Size - Wood |
|
| Features |
|
| Material |
|
| Maximum Door Weight |
|
| Product Description |
|
| Size | Gauge of Metal | Hole Count | Screw Size (Wood) |
| 3 1/2 x 3 1/2 (89 mm x 89 mm) |
0.106 | 6 | 3/4 x 9 FH |
| 4 x 4 (102 x 102 mm) |
0.106 |
8 | 1 x 9 FH |
| Size | Recommended Max Door Weight |
Bearing Hinge |
Spring Hinge Location |
| 3-1/2" x 3-1/2" 4" x 4" |
45 lbs. 70 lbs. 90 lbs. |
2 1 - |
1 Center 2 Center/Bottom 3 All |
Downloads:
Specifications
Notes
Note: For maximum versatility use all spring hinges or a combination of spring hinges and ball bearing hinges. Do not use plain bearing hinges. Full spring tension may not be required on all hinges. Strong wind conditions, drafts, carpeting drag, twisted/misaligned frames, or weatherstripping on doors may require additional spring hinges.
