IC Realtime - NVR-FX08POE-1U4K1 / 8Ch Rack-Mount NVR / 16TB Max (Starting At 2TB HDD) / Integrated 8 Port POE / 8MP IP Support / 128Mbps Bandwidth
Available to Order
SKU:
ICR-NVR-FX08POE-1U4K1-2TB
NSID:
68605
- $1,578.00
-
$1,893.60 - $1,578.00
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
- 8 Channels | Up to 8MP | 128Mbps Bandwidth
- 2 HDDs | 16TB Max (Starting at 2TB HDD)
- ICR OS 4.0 |Built-In 8 port PoE | AI + IVS Support
- 2 USB | Alarm 4/1 | 1 HDMI + 1 VGA
- ONVIF 2.4 |1U | Rack-mountable
- Made in South Korea and conforms to the Trade Agreements Act (TAA)
THE TAA-CERTIFIED 4K BLADE NVR YOU NEED
AV and IT professionals already know that their clients demand 4K ultra-high definition for cutting edge video. And their experience already tells them that the best place for any gear with a lot of wired connections is a 19” open bay rack. So IC Realtime did what it always does. We listened to our expert customers and designed the professional & perfect 8 channel 4K NVR in a slim, clean, rack mount blackout case that will quickly become any professional installer’s ideal “go-to” NVR.
IC Realtime proudly presents the TAA compliant, South Korean-made NVR-FX08POE-1U4K1.DEPENDABLE FLEXIBILITY
Based on our dependable 1U chassis and with a built-in eight port PoE switch, the FX08 is IC Realtime’s newest 4K rendition of the industry’s most reliable, best value rack mount 8 channel NVR. The dedicated backplane 8 port camera switch not only saves rack space, it makes camera installation plug & play easy.
This flexible unit fits in any situation. The FX08 rack ears are removable, so it’s also comfortable on a closet shelf, lockbox, or desktop. But with so many businesses, schools, and high-end homes already wired with CAT5/6 & wire raceways that usually terminate in an equipment closet or rack cabinet, the FX08 is ideal. For any installation site that already has rack space available, such as high-end AV installations, retail stores & warehouses, or any business with rackmount network or IP phone systems with PoE switches, the FX08 can “rack in” wherever a 1U network switch can fit.
AI-ASSISTED 8 CHANNEL 4K SOLUTION
Installation convenience is meaningless without state-of-the-art performance, so IC Realtime designed in full 4k recording and 4K HDMI video output into the FX08 from the start. The embedded Linux industrial-grade processor boasts 128 Mbps throughput coupled to a built-in 8 port 115 watt PoE switch (single port max is 25.5W) and H.265 high compression video encoding. There are 2 SATAIII hard drive bays for a max of 16TB onboard storage (2X 8TB) and 4K HDMI output. FX08 will record all 8 cameras at 1080P or 2 cameras at 4K resolution and is ONVIF (profile S), CGI, SDK & P2P compatible.
FX08 is part of IC Realtime’s FlexSmartAi family of security tools, meaning it works with our AI & deep learning cameras, encoding & recording that camera-based data in the video stream from all it’s IP camera ports. Camera-based Intelligent Motion Detection (IMD) utilizes a deep learning algorithm that recognizes people and vehicles with up to 95% accuracy to reduce or eliminate false alarms. IVS (Intelligent Video System) cameras can be set up to detect abandoned or missing objects or tripwire and intrusion detection areas. The FX08 will record those violation and intrusion events.
SCALEABLE RACK & STACK PoE BLADE
As a standalone 8 channel 4K NVR, the FX08 offers unparalleled performance, but it’s even better when it joins with it’s brother IC Realtime NVRs in larger installations. Like it’s sister 16 channel rack-mountable NVR, the FX16POE-1U4K1, the FX08 can serve as a rack-mounted 8 channel “Blade NVR & POE Switch” in a distributed processing & video security storage system. No matter how many cameras in a system, adding rack-mountable camera “nodes” in 8 & 16 channel increments and directly connected onsite “client” cameras can grow up to whatever camera capacity the job requires with no worries about throughput and storage capacity. Each “node” in the system is a full 16TB capacity dual hard drive NVR with an on-chassis PoE switch, a massive 128Mbps Linux-based processor core, and a 1000Mbs network port.
REALISTIC DISTRIBUTED RECORDING
Then - using IC Realtime’s freely downloadable SmartICRSS v2 Remote Client Software - every recorder and IP camera in your system - locally or anywhere in the world - can then be centrally monitored, accessed & controlled from your PC or Mac desktop. Imagine the possibilities for a distributed system like this for a firm or institution with legally mandated video supervision & recording, where 100% recording uptime is essential. Extra channels on an on-rack recorder (i.e. a 16 channel NVR supporting 8 cameras) or even a stand-by NVR already installed can change major panic into a minor annoyance. SmartICRSS software is free to download at https://icrealtime.com/downloads.
LICENSE-FREE PEACE OF MIND
License-free “Central Station” and essential camera stand-by capability has never been so easy and freely available, and IC Realtime has never charged annual IP licensing fees - and never will. To ensure device & network security, all IC Realtime cameras & recorders are protected from cyber threats by multiple layers of authorizations & password protections. All network traffic is encrypted in both directions to a point where our gear now meets the newest network UL CAP certification standards.
BUILD-OUT THE FUTURE
Of course, seeing is believing. The NVR-FX08POE is part of the IC Realtime Video Ecosystem, and all our FlexSmartAi FX series NVRs represents the next generation of 4k resolution, AI-enhanced Network Video Recorders.
