Details
Specifications:
| For Use With: | For Aluminum Stile Doors |
| Features: | -Key controlled bolt holdback feature offers flexibility for traffic control on buildings that require free entrance during specific times and exit only for others -Auxiliary latch bolt feature when in a locked position provides additional security |
| Faceplates: | Clear Aluminum & Dark Bronze |
| Grade: | Cycle testing exceeds ANSI Grade 1 standards |
| Construction: | Steel case with corrosion-resistant plating |
| Cylinder: | Accepts standard 1 5/32" (29.36 mm) Zinc or Brass threaded mortise cylinder (Cylinder not Included) |
| Accepts Deadlatch: | Interchangeable with 185 Series Deadbolts |
| Backset: | 1 1/8" (28.58 mm) |
| Latchbolt Dimension: | 5/8"W x 1 1/2"L (15.88 mm x 38.1 mm) |
| Throw: | 1 3/8" (34.9 mm) |
