Jonard Tools - CAT5e RJ45 Pass-Through Connectors (Pack of 25)
Available to Order
SKU:
JND-RJ45-525
NSID:
45140
- $12.95
-
$14.34 - $12.95
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
The Jonard Tools CAT5e RJ45 Pass-Through Connectors are used by network installers/technicians in order to terminate CAT5e network cables with a pass-through crimper. They are used in households and businesses and are ideal for terminating a round network cable or even replacing an existing connector. These connectors feature the following:
- 50 μin gold plating on contact surfaces provides greater signal quality than the competition
- Tripoint-type prongs allow you to use stranded or solid CAT5/CAT5e cables
- Simplify twisted pair network cable termination by allowing the wires to pass through the connector
- Advantage of the pass-through feature is that you do not have to measure and cut the wires before termination, which can lead to having poor connection and signal loss
- Clear housing allows the operator to see the wire pairs easily
This product comes in a bag of 25 connectors.
Intended for use with our RJ11 and RJ45 connector crimping tool: UC-4569
Specifications
| Number of Connectors |
25 |
|---|---|
| Cable Type |
CAT5, CAT5e Network Cables |
| Connector Type |
Three-prong RJ45 |
| Plating Thickness |
50 micro-inches |
| Housing Material |
Polycarbonate |
| Standards |
UL 94V-2, RoHS Compliant |
| Operating Temperature |
-10°C to 60°C |
| Dimensions | 0.88 in x 0.46 in x 0.36 in (2.24 cm x 1.17 cm x 0.91 cm) |
| Weight | 0 lb (0.908 g) |
| UPC # | 810053350591 |
